| Hardware |
| Hardware Type |
Indoor Universal AP |
| Number of Radios |
2 |
| Number of Antennas |
8 RP-SMA External and 1 Bluetooth/BLE Internal |
| Peak Antenna Gain |
3 dBi for 2.4 GHz, 3 dBi for 5 GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Frequency of Radio 1 |
2.4 GHz b/g/n 20/40 MHz (64 QAM) |
| Frequency of Radio 2 |
5 GHz a/n/ac 20/40/80/160 MHz (256 QAM) MU-MIMO 3 simultaneous devices |
| Maximum Data Rate |
Radio 1: up to 600 Mbps
Radio 2: up to 1,733 Mbps |
| Tx/Rx Streams |
4x4 MIMO 4 spatial stream |
| Bluetooth Low Energy (BT/BLE) Radio |
Bluetooth scanning and iBeacon advertisement @ 4 dBm max TX power |
| Ethernet Ports |
2x GE RJ45 |
| USB Port |
1x Type A |
| Serial Console Port |
1 RS-232 x RJ45 |
| Power over Ethernet (PoE) |
Dual redundant PoE power ports with support for IEEE 802.3at (2x2 @ 17 dBm with 802.3af; USB disabled) |
| Simultaneous SSIDs |
16 (14 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
2.4 GHz: 28 dBm / 630 mW (4 chains combined)
5 GHz: 26 dBm / 398 mW (4 chains combined) |
| Physical Security |
Kensington Lock |
| IEEE Specifications |
802.11a, 802.11ac, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n, 802.1x, 802.3af, 802.3at, 802.3az |
| Wireless Mesh Capable |
Yes |
| FortiPresence Capable |
Yes |
| Modes of Operation |
WLC 8.2 (min.), FortiGate, (FortiCloud – Future) |
| SSID Types Supported |
Local-Bridge, Tunnel & Mesh (when managed by FortiGate) |
| FortiDeploy and FortiCloud Key |
Yes |
| Per Radio Client Capacity |
Up to 256 |
| LED Off Mode |
Yes |
| Advanced 802.11 Features |
| 802.11ac MU-MIMO Wave 2 |
Yes |
| Transmit Beam Forming (TxBF) |
Yes |
| Low-Density Parity Check (LDPC) Encoding |
Yes |
| Maximum Likelihood Demodulation (MLD) |
Yes |
| Maximum Ratio Combining (MRC) |
Yes |
| A-MPDU and A-MSDU Packet Aggregation |
Yes |
| MIMO Power Save |
Yes |
| Short Guard Interval |
Yes |
| WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic) |
| Wireless Monitoring Capabilities |
| Frequencies scanned |
2.4 and 5 GHz |
| Background scan with client access on 2.4 and 5 GHz |
Yes |
| Full-time scan as dedicated monitor |
Yes |
| Packet sniffer mode |
Yes |
| Spectrum analyzer |
Yes |
| Dimensions |
| Length x Width x Height |
8.46 x 8.46 x 2.2 inches (215 x 215 x 56 mm) |
| Weight |
3.4 lb (1.53 kg) |
| Package (shipping) Weight |
5.36 lb (2.43 kg) |
| Mounting Options |
Ceiling, T-Rail and Wall |
| Included Accessories |
Ceiling, T-Rail and wall mount kit and 8 dipole antennas (AC power adapter sold separately) |
| Environment |
| Power Supply |
Adapter input: 100–240V, 50/60Hz, 0.9A Maximum output: 12V DC, 3A |
| Power Consumption (Average / Maximum) |
24.5 W max power draw in 802.3at mode and 12.5 W max power draw when supplied with 802.3af mode (operates in 2x2 mode) |
| Humidity |
5–90% non-condensing |
| Operating Temperature |
-4–122°F (-20–50°C) |
| Storage Temperature |
-40–158°F (-40–70°C) |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
No |
| Mean Time Between Failures |
>30 Years |
| Hit-less PoE Failover |
Yes |
| Compliance |
| SAFETY |
FCC: FCC Part 15 Subpart B (Class B), Subpart C and Subpart E
UL: UL 609550-1, UL 2043, CSA C22.2 No. 60950-1
CB: IEC 60950-1
|
| RF |
IC: RSS-210, RSS-GEN, RSS-102, ICES-003 |
| Certifications |
| WiFi Alliance Certified |
Yes |
| DFS Certified |
Yes |
