FG-400E Tường lửa Firewall Fortigate 400E Series
| FortiGate Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Firewall Fortinet FortiGate FG-400E cung cấp khả năng tường lửa thế hệ mới cho các doanh nghiệp vừa và lớn, với sự linh hoạt được triển khai tại các doanh nghiệp hoặc các chi nhánh.
FG-400E Datasheet
Thiết bị tường lửa thế hệ mới Firewall FortiGate FG-400E giúp chống lại các mối đe dọa trên mạng với bộ xử lý bảo mật cung cấp hiệu suất cao, hiệu quả bảo mật và khả năng hiển thị chi tiết các vấn đề bảo mật.
Thông số kỹ thuật Firewall FortiGate FG-400E
| Interfaces and Modules |
| GE RJ45 Interfaces |
16 |
| GE SFP Slots |
16 |
| GE RJ45 Management Ports |
2 |
| USB Ports |
2 |
| RJ45 Console Port |
1 |
| Local Storage |
NIL |
| Included Transceivers |
2x SFP (SX 1 GE) |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
7.8 Gbps |
| NGFW Throughput |
6 Gbps |
| Threat Protection Throughput |
5 Gbps |
| System Performance and Capacity |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
32 / 32 / 24 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
32 / 32 / 24 Gbps |
| Firewall Latency (64 byte, UDP) |
2.4 μs |
| Firewall Throughput (Packet per Second) |
36 Mpps |
| Concurrent Sessions (TCP) |
4 Million |
| New Sessions/Second (TCP) |
450,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
20 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| SSL-VPN Throughput |
4.5 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
4.8 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
4,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
300,000 |
| Application Control Throughput (HTTP 64K) |
12 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
14.8 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
72 |
| Maximum Number of FortiAPs (Total / Tunnel) |
512 / 256 |
| Maximum Number of FortiTokens |
5,000 |
| Maximum Number of Registered FortiClients |
600 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| Dimensions and Power |
| Height x Width x Length (inches) |
1.75 x 17.0 x 15.0 |
| Height x Width x Length (mm) |
44.45 x 432 x 380 |
| Weight |
16.4 lbs (7.4 kg) |
| Form Factor |
1 RU |
| Power Consumption (Average / Maximum) |
109 W / 214 W |
| Power Source |
100–240V 60–50Hz |
| Current (Maximum) |
6A |
| Heat Dissipation |
730 BTU/h |
| Redundant Power Supplies (Hot Swappable) |
optional |
| Operating Environment and Certifications |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
10–90% non-condensing |
| Noise Level |
48 dBA |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
| |
|
Tùy chọn sử dụng cho Firewall FortiGate FG-400E
| 1 GE SFP LX transceiver module |
FG-TRAN-LX |
1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots |
| 1 GE SFP RJ45 transceiver module |
FG-TRAN-GC |
1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots |
| 1 GE SFP SX transceiver module |
FG-TRAN-SX |
1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots |
| Optional Power Supply |
SP-FG300E-PS |
AC power supply for FG-300/301E, FG-400/401E, FG-500/501E, FG-600/601E, FAZ-200F/300F/800F and FMG-200F/300F |
Các tùy chọn Option, License cho FG-400E
Fortinet FortiGate-400E 360 Protection (ASE FortiCare plus App Ctrl, IPS, AV, Web Filtering, AS, FSA Cloud, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter S
FortiGate-400E 1 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-0400E-817-02-12
List Price: Liên hệ
FortiGate-400E 3 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-0400E-817-02-36
List Price: Liên hệ
FortiGate-400E 5 Year 360 Protection (ASE FortiCare plus App Ctrl, IPS, AMP, Web Filtering, AS, Security Rating, IoT Detection, SD-WAN Orchestrator/Cloud Monitoring/Overlay Ctrl VPN, FMG/FAZ/IPAM Cloud, Industrial Security and FortiConverter Svc)
#FC-10-0400E-817-02-60
List Price: Liên hệ
Fortinet FortiGate-400E Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering, Antispam, FortiSandbox Cloud, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
FortiGate-400E 1 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-0400E-811-02-12
List Price: Liên hệ
FortiGate-400E 3 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-0400E-811-02-36
List Price: Liên hệ
FortiGate-400E 5 Year Enterprise Protection (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering, Antispam, IoT Detection, Industrial Security, Security Rating, and FortiConverter Svc)
#FC-10-0400E-811-02-60
List Price: Liên hệ
Fortinet FortiGate-400E IoT Detection Service
FortiGate-400E 1 Year IoT Detection Service
#FC-10-0400E-231-02-12
List Price: Liên hệ
Fortinet FortiGate-400E FortiIPAM Cloud Service
FortiGate-400E 1 Year FortiIPAM Cloud Service
#FC-10-0400E-233-02-12
List Price: Liên hệ
Fortinet FortiGate-400E SD-WAN Orchestrator Entitlement License
FortiGate-400E 1 Year SD-WAN Orchestrator Entitlement License
#FC-10-0400E-319-02-12
List Price: Liên hệ
Fortigate 400E Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud)
FortiGate-400E 1 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-0400E-950-02-12
List Price: Liên hệ
FortiGate-400E 3 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-0400E-950-02-36
List Price: Liên hệ
FortiGate-400E 5 Year Unified Threat Protection (UTP) (24x7 FortiCare plus Application Control, IPS, AMP, Web Filtering and Antispam Service)
#FC-10-0400E-950-02-60
List Price: Liên hệ
Fortigate 400E Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS, AV and FortiSandbox Cloud)
FortiGate-400E 1 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-0400E-928-02-12
List Price: Liên hệ
FortiGate-400E 3 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-0400E-928-02-36
List Price: Liên hệ
FortiGate-400E 5 Year Advanced Threat Protection (24x7 FortiCare plus Application Control, IPS and AMP Service)
#FC-10-0400E-928-02-60
List Price: Liên hệ
Fortigate 400E FortiGate Cloud Management, Analysis and 1 Year Log Retention
FortiGate-400E 1 Year FortiGate Cloud Management, Analysis and 1 Year Log Retention
#FC-10-0400E-131-02-12
List Price: Liên hệ
FortiGate-400E 3 Year FortiGate Cloud Management, Analysis and 1 Year Log Retention
#FC-10-0400E-131-02-36
List Price: Liên hệ
FortiGate-400E 5 Year FortiGate Cloud Management, Analysis and 1 Year Log Retention
#FC-10-0400E-131-02-60
List Price: Liên hệ
Fortigate 400E FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiSandbox Cloud Service
FortiGate-400E 1 Year FortiGuard Advanced Malware Protection (AMP) including Antivirus, Mobile Malware and FortiGate Cloud Sandbox Service
#FC-10-0400E-100-02-12
List Price: Liên hệ
Fortigate 400E FortiGuard IPS Service
FortiGate-400E 1 Year FortiGuard IPS Service
#FC-10-0400E-108-02-12
List Price: Liên hệ
Fortigate 400E FortiGuard Web Filtering Service
FortiGate-400E 1 Year FortiGuard Web Filtering Service
#FC-10-0400E-112-02-12
List Price: Liên hệ
Fortigate 400E FortiGuard Industrial Security Service
FortiGate-400E 1 Year FortiGuard Industrial Security Service
#FC-10-0400E-159-02-12
List Price: Liên hệ
Fortigate 400E FortiGuard Security Rating Service
FortiGate-400E 1 Year FortiGuard Security Rating Service
#FC-10-0400E-175-02-12
List Price: Liên hệ
Fortigate 400E SD-WAN Cloud Assisted Monitoring: Cloud-based SD-WAN Bandwidth & Quality Monitoring Service
FortiGate-400E 1 Year SD-WAN Cloud Assisted Monitoring: Cloud-based SD-WAN Bandwidth & Quality Monitoring Service
#FC-10-0400E-288-02-12
List Price: Liên hệ
Fortigate 400E SD-WAN Overlay Controller VPN Service: Cloud-based SD-WAN VPN Overlay Service & Portal
FortiGate-400E 1 Year SD-WAN Overlay Controller VPN Service: Cloud-based SD-WAN VPN Overlay Service & Portal
#FC-10-0400E-289-02-12
List Price: Liên hệ
Fortigate 400E FortiManager Cloud: Cloud-based Central Management & Orchestration Service
FortiGate-400E 1 Year FortiManager Cloud: Cloud-based Central Management & Orchestration Service
#FC-10-0400E-179-02-12
List Price: Liên hệ
Fortigate 400E FortiAnalyzer Cloud: Base subscription for Cloud-based Events Management & Analytics Service
FortiGate-400E 1 Year FortiAnalyzer Cloud: Cloud-based Events and Security Log Monitoring including IOC Service
#FC-10-0400E-188-02-12
List Price: Liên hệ
Fortigate 400E FortiConverter Service for one time configuration conversion service
FortiGate-400E 1 Year FortiConverter Service for one time configuration conversion service
#FC-10-0400E-189-02-12
List Price: Liên hệ
Fortigate 400E 24x7 FortiCare Contract
FortiGate-400E 1 Year 24x7 FortiCare Contract
#FC-10-0400E-247-02-12
List Price: Liên hệ
FortiGate-400E 3 Year 24x7 FortiCare Contract
#FC-10-0400E-247-02-36
List Price: Liên hệ
FortiGate-400E 5 Year 24x7 FortiCare Contract
#FC-10-0400E-247-02-60
List Price: Liên hệ
Fortigate 400E ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
FortiGate-400E 1 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-0400E-284-02-12
List Price: Liên hệ
FortiGate-400E 3 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-0400E-284-02-36
List Price: Liên hệ
FortiGate-400E 5 Year ASE FortiCare (24x7 plus Advanced Services Ticket Handling)
#FC-10-0400E-284-02-60
List Price: Liên hệ
Fortigate 400E Next Day Delivery Premium RMA Service (requires 24x7 support)
FortiGate-400E 1 Year Next Day Delivery Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-0400E-210-02-12
List Price: Liên hệ
Fortigate 400E 4-Hour Hardware Delivery Premium RMA Service (requires 24x7 support)
FortiGate-400E 1 Year 4-Hour Hardware Delivery Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-0400E-211-02-12
List Price: Liên hệ
Fortigate 400E 4-Hour Hardware and Onsite Engineer Premium RMA Service (requires 24x7 support)
FortiGate-400E 1 Year 4-Hour Hardware and Onsite Engineer Premium RMA Service (Requires 24x7 or ASE FortiCare)
#FC-10-0400E-212-02-12
List Price: Liên hệ
Fortigate 400E Secure RMA Service
FortiGate-400E 1 Year Secure RMA Service
#FC-10-0400E-301-02-12
List Price: Liên hệ
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: FG-400E ?
Thiết bị Firewall FortiGate FG-400E hoạt động tốt và ổn định nhất ở trong môi trường có nhiệt độ từ 0°C đến 40°C ạ
Thông tin chi tiết về các license của Firewall FortiGate FG-400E-BDL-950-12 đã được gửi đến mail của bạn. Bạn vui lòng check mail nhé. Nếu có thắc mắc gì khác, bạn có thể liên hệ với shop để được giải đáp.
Thông tin về các tính năng của Firewall FortiGate FG-400E cùng với datasheet của sản phẩm đã được gửi vào mail của bạn, bạn vui lòng check giúp shop nha. Nếu có thắc mắc gì khác, hãy liên hệ với shop qua hotline 0906.051.599 để được tư vấn một cách chi tiết hơn bạn nhé
Anh có thể lựa chọn các giải pháp lưu log trên FG-400E như: FortiManager, FortiAnalyzer, FortiCloud, qua hệ thống syslog của các bên thứ 3 anh nhé.
CNTTShop đã gửi báo giá Fortigate 400E qua email, anh vui lòng check inbox nhé.
