| Interfaces and Modules |
| 40/100 GE QSFP28 Slots |
4 |
| 1/10/25 GE SFP28 Slots |
24 |
| 10 GE SFP+ Slots |
3 |
| GE RJ45 Management Ports |
2 |
| USB Ports |
1 |
| RJ45 Console Port |
1 |
| Local Storage |
N/A |
| Included Transceivers |
2x SFP+ (SR 10 GE) |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
110 Gbps |
| NGFW Throughput |
90 Gbps |
| Threat Protection Throughput |
60 Gbps |
| System Performance and Capacity |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
239 / 238 / 135 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
239 / 238 / 135 Gbps |
| Firewall Latency (64 byte, UDP) |
5 μs |
| Firewall Throughput (Packet per Second) |
202.5 Mpps |
| Concurrent Sessions (TCP) |
120 Million |
| New Sessions/Second (TCP) |
2 Million |
| Firewall Policies |
200,000 |
| IPsec VPN Throughput (512 byte) |
96 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
16,000 |
| Client-to-Gateway IPsec VPN Tunnels |
90,000 |
| SSL-VPN Throughput |
9 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
30,000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
66 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
30,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
10 Million |
| Application Control Throughput (HTTP 64K) |
150 Gbps |
| CAPWAP Throughput (HTTP 64K) |
N/A |
| Virtual Domains (Default / Maximum) |
10 / 500 |
| Maximum Number of FortiSwitches Supported |
N/A |
| Maximum Number of FortiAPs (Total / Tunnel) |
N/A |
| Maximum Number of FortiTokens |
20,000 |
| Maximum Number of Registered FortiClients |
100,000 |
| High Availability Configurations |
Supported |
| Dimensions and Power |
| Height x Width x Length (inches) |
5.20 x 17.20 x 26.18 |
| Height x Width x Length (mm) |
132 x 437 x 665 |
| Weight |
67.68 lbs (30.7 kg) |
| Form Factor |
3 RU |
| Power Consumption (Average / Maximum) |
(977 / 1,217 W) / (977 / 1,237 W) |
| Power Source |
100–240V AC, 50–60 Hz |
| Current (Maximum) |
30A@100VAC, 20A@240VAC |
| Heat Dissipation |
4,153 / 4,221 BTU/h |
| Redundant Power Supplies (Hot Swappable) |
2+1 Redundant, Hot Swappable |
| Operating Environment and Certifications |
| Operating Temperature |
32–104°F (0–40°C) |
| Storage Temperature |
-31–158°F (-35–70°C) |
| Humidity |
10–90% non-condensing |
| Noise Level |
57.43 dBA |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
