| Hardware |
| Hardware Type |
Outdoor/Outdoor AP |
| Number of Radios |
2 |
| Number of Antennas |
4 N-type External, 1 RP-SMA for BLE |
| Peak Antenna Gain |
5 dBi for 2.4 GHz, 7 dBi for 5 GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725,
5.725–5.850 |
| Frequency of Radio 1 |
2.4 GHz b/g/n (2x2:2 stream) 20/40 MHz (256 QAM)) |
| Frequency of Radio 2 |
5 GHz a/n/ac (2x2:2 stream) 20/40/80 MHz (256 QAM)
MU-MIMO 2 simultanous devices |
| Maximum Data Rate |
Radio 1: up to 400 Mbps, Radio 2: up to 867 Mbps |
| Ethernet Ports |
1x GE RJ45 (PoE) |
| Serial Console Port |
Internal console port |
| Power over Ethernet (PoE) |
IEEE 802.3af/at (12.5 W / 30 W) |
| Simultaneous SSIDs |
16 (14 if background
scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2,
PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key, WEP and
Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
22 dBm (158 mW) @ 2.4 GHz per chain*
22 dBm (158 mW) @ 5 GHz per chain* |
| Physical Security |
N/A |
| IEEE Specifications |
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h,
802.11i, 802.11j, 802.11n, 802.1x, 802.3af, 802.11ac,
802.3at, 802.3az |
| FortiPresence Capable |
Yes |
| Wireless Mesh Capable |
Yes |
| Per Radio Client Capacity |
Up to 512 |
| Modes of Operation |
FortiGate or FortiCloud management |
| SSID Types Supported |
Local-Bridge, Tunnel & Mesh (when managed by controller) |
| FortiDeploy & FortiCloud Key |
Yes |
| LED Off Mode |
Yes |
| Reg Domain |
International |
| Advanced 802.11 Features |
| 802.11ac Wave 2 MU-MIMO |
Yes |
Transmit Beam Forming
(TxBF) |
Yes |
Low-Density Parity Check
(LDPC) Encoding |
Yes |
Maximum Likelihood
Demodulation (MLD) |
Yes |
Maximum Ratio Combining
(MRC) |
Yes |
802.11ac 20/40/80 MHz
Channel |
Yes |
A-MPDU and A-MSDU
Packet Aggregation |
Yes |
| MIMO Power Save |
Yes |
| Short Guard Interval |
Yes |
| WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic) |
| Wireless Monitoring Capabilities |
| Frequencies Scanned |
2.4 and 5 GHz |
Background Scan with Client
Access on 2.4 and 5 GHz |
Yes |
Full-time Scan as
Dedicated Monitor |
Yes |
Full-time Scan with Client
Access on 5G GHz |
No |
| Packet Sniffer Mode |
Yes |
| Spectrum Analyzer |
Yes |
| Dimensions |
| Diameter x Height |
9.8 x 8.66 x 2.08 inches (249 x 220 x 53 mm) |
| Weight |
3.82 lb (1,735 g) |
| Package (shipping) Weight |
5.82 lb (2.64 kg) |
| Mounting Options |
Wall or pole |
| Included Accessories |
Wall/Pole mount kit and 6M grounding cable, 4 WiFi antenna +
1 BLE antenna, power injector |
| Environment |
| Power Supply |
PSE Device |
| Power Consumption (Avg.) |
13.5 W |
| Power Consumption (Max.) |
17.5 W |
| Humidity |
5–90% non-condensing |
| Operating Temperature |
-4–122°F (-20–50°C) |
| Storage Temperature |
-40–158°F (-40–70°C) |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
N/A (Top Cover) |
| Mean Time Between Failures |
>10 Years |
| IP Rating |
IP67 |
| Surge Protection Built In |
Yes |
| Certifications |
| WiFi Alliance Certified |
Yes |
| DFS Certified for Europe |
Yes |
| CB |
IEC 60950-1 |
| UL |
UL 609550-1,CSA C22.2 No. 60950-1 |
| FCC |
FCC Part 15 Subpart B (Class B), Subpart C and Subpart E |
| IC |
RSS-247, RSS-GEN, RSS-102, ICES-003 |
| CE |
CE R&TTE Directive 2014/53/EU (EN 300 328, EN 301 893,
EN 301 489
EMC Directive 2004/108/EC (EN55032, EN 55024 |
| Warranty |
| Limited Lifetime Warranty |
1 Year |
