FWF-90D Firewall FortiWiFi 16x GE RJ45 ports (2x WAN ports, 14x Switch ports), Wireless 802.11a/b/g/n, 32 GB storage, Max managed FortiAPs (Total / Tunnel) 32 / 16
Firewall Fortinet FortiWiFi FWF-90D cung cấp một giải pháp an ninh mạng tuyệt vời được thiết kế để bàn không quạt nhỏ gọn cho các văn phòng chi nhánh của doanh nghiệp và các doanh nghiệp vừa và nhỏ. Firewall FortiGate FWF-90D bảo vệ chống lại các mối đe doạ trực tuyến bằng giải pháp SD-WAN an toàn hàng đầu trong ngành công nghiệp, giải pháp đơn giản, giá cả phải chăng và dễ triển khai.

View datasheet fortigate
FortiGate entry-level firewalls include
Interfaces and Modules |
GE RJ45 WAN Ports |
2 |
GE RJ45 Switch Ports |
14 |
GE RJ45 PoE Ports |
- |
Wireless Interface |
802.11 a/b/g/n |
USB Ports (Client / Server) |
1 / 2 |
Console (RJ45) |
1 |
Internal Storage |
32 GB |
System Performance and Capacity |
Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
3.5 / 3.5 / 3.5 Gbps |
Firewall Latency (64 byte, UDP) |
4 μs |
Firewall Throughput (Packet per Second) |
5.3 Mpps |
Concurrent Sessions (TCP) |
2 Million |
New Sessions/Sec (TCP) |
4,000 |
Firewall Policies |
5,000 |
IPsec VPN Throughput (512 byte) |
1 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels |
200 |
Client-to-Gateway IPsec VPN Tunnels |
2,500 |
SSL-VPN Throughput |
35 Mbps |
Concurrent SSL-VPN Users |
200 |
SSL Inspection Throughput (IPS, HTTP) |
18 Mbps |
Application Control Throughput |
100 Mbps |
CAPWAP Throughput (1444 byte, UDP) |
260 Mbps |
Virtual Domains (Default / Maximum) |
10 / 10 |
Maximum Number of Switches Supported |
8 |
Maximum Number of FortiAPs (Total / Tunnel Mode) |
32 / 16 |
Maximum Number of FortiTokens |
100 |
Maximum Number of Registered FortiClients |
200 |
High Availability Configurations |
Active / Active, Active / Passive, Clustering |
System Performance — Optimal Traffic Mix |
IPS Throughput |
275 Mbps |
System Performance — Enterprise Traffic Mix |
IPS Throughput |
50 Mbps |
NGFW Throughput |
30 Mbps |
Threat Protection Throughput |
25 Mbps |
Dimensions and Power |
Height x Width x Length (inches) |
1.72 x 9.2 x 8.78 |
Height x Width x Length (mm) |
44 x 234 x 223 |
Weight |
3.5 lbs (1.6 kg) |
Thông số kỹ thuật Firewall FortiWiFi FWF-90D
Environment |
Power Required |
100–240V AC, 50–60 Hz |
Maximum Current |
110 V / 1.5 A, 220 V / 0.75 A |
Total Available PoE Power Budget |
N/A |
Power Consumption (Average / Maximum) |
21 / 25 W |
Heat Dissipation |
85 BTU/h |
Operating Temperature |
32–104°F (0–40°C) |
Storage Temperature |
-31–158°F (-35–70°C) |
Humidity |
10–90% non-condensing |
Noise Level |
Fanless 0 dBA |
Operating Altitude |
Up to 7,400 ft (2,250 m) |
Compliance |
FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB |
Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
Optional Accessory
Rack mount tray |
SP-RACKTRAY-01 |
Rack mount tray for FG-30D, FG-40C, FG-50/51E, FG-60C, FG-60D/-POE, FG-70D, FG-80D, FG-90D/-POE, FAD-100E, FRC-100D, FWB-100D, FML-60D, FVE-100E |
