| Datasheet JL815A |
| Specifications |
| I/O ports and slots |
48 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3at Class 4 PoE (ports 1-24) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
4 SFP 1GbE ports
|
| Physical Characteristics |
| Dimensions |
351.0(d) x 443.0(w) x 43.9(h) mm |
| Weight |
10.90 lb (4.94 kg) |
| Memory and Flash |
ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5MB |
| Performance |
| Throughput (Mpps) |
77.37 Mpps |
| Switching capacity |
104 Gbps |
| 100 Mb latency |
< 5.2 uSec |
| 1000 Mb latency |
< 2.8 uSec |
| MAC address table size (# of entries) |
16,000 entries |
| Reliability MTBF (years) |
83.5 |
| Environment |
| Operating temperature |
32°F to 104°F (0°C to 40°C) |
| Operating relative humidity |
15% to 95% @ 104°F (40°C) |
| Nonoperating/ storage temperature |
-40°F to 158°F (-40°C to 70°C) |
| Nonoperating/ storage relative humidity |
15% to 95% @ 140°F (60°C) |
| Altitude |
up to 10,000 ft (3 km) |
| Acoustics1 |
| Idle |
LWAd = 3.5 Bel LpAm (Bystander) = 20 dB |
| 100% traffic |
LWAd = 3.5 Bel LpAm (Bystander) = 20 dB |
| 100% traffic / 0% PoE |
LWAd = 3.5 Bel LpAm (Bystander) = 20 dB |
| 100% traffic / 50% PoE |
LWAd = 4.0 Bel LpAm (Bystander) = 25 dB |
| 100% traffic / 100% PoE |
LWAd = 5.7 Bel LpAm (Bystander) = 41 dB |
| Electrical Characteristics |
| Frequency |
50Hz/60Hz |
| AC voltage |
100-127VAC / 200- 240VAC |
| Current |
5.2A/2.6A |
| Maximum power rating |
100-127V: 462.5W 200-220V: 452.5W |
| Idle power |
100-127V: 25.8W 200-220V: 25.4W |
| PoE power |
370 W Class 4 PoE |
| Power supply |
Internal power supply |
| Safety |
EN/IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
EN/IEC 62368-1, 2nd. & 3rd. Ed.
UL 62368-1, 2nd. & 3rd. Ed.
CAN/CSA C22.2 No. 62368-1, 2nd. & 3rd. Ed.
EN/IEC 60825-1:2014 Class 1
|
| Emissions |
EN 55032:2015/CISPR 32, Class A
FCC CFR 47 Part 15: 2018 Class A
ICES-003 Class A
VCCI Class A
CNS 13438 Class A
KN 32 Class A
AS/NZS CISPR 32 Class A
|
| Immunity |
| Generic |
EN 55035, CISPR 35, KN35 |
| EN |
EN 55035, CISPR 35 |
| ESD |
EN/IEC 61000
-4-2 |
| Radiated |
EN/IEC 61000
-4-3 |
| EFT/Burst |
EN/IEC 61000
-4-4 |
| Surge |
EN/IEC 61000
-4-5 |
| Conducted |
EN/IEC 61000
-4-6 |
| Power frequency magnetic field |
EN/IEC 61000
-4-8 |
| Voltage dips and interruptions |
EN/IEC 61000-4-11 |
| Harmonics |
EN/IEC 61000
-3-2 |
| Flicker |
EN /IEC 61000-3-3 |
| Device Management |
Aruba Instant On Cloud; Web browser; SNMP Manager |
| Mounting |
| Mounting positions and supported racking |
Mounts in an EIAstandard 19 in. telco rack or equipment cabinet. 2-post rack kit included
Supports table-top mounting
Supports rack-mounting
Supports wall-mounting with ports facing either up or down
Supports under-table mounting using the brackets provided
|
Switch
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: JL815A ?
Thông số phần cứng của switch Aruba JL815A là: CPU ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash, packet buffer: 1.5MB
Switch Aruba JL815A có throughput là 77.37 Mpps, switching capacity là 104 Gbps ạ
Switch Aruba JL815A hỗ trợ 24 cổng PoE class 4 với tổng suất là 370W ạ
Switch Aruba JL815A thuộc dòng switch dòng switch Smart-Managed rất nhỏ gọn ạ
Switch Aruba JL815A có thể hoạt động ở nhiệt độ từ 32°F to 104°F (0°C to 40°C) và độ ẩm là 15% to 95% @ 104°F (40°C)
