Maipu PT4330-16 GPON OLT

Item

PT4330-16

Rack

1U 19 Inch Standard Box

RJ45(1G)

4

SFP(1G)

/

SFP+(10G)

4

GPON Port

16

Connector Type

Class (Class C++/Class C+++)

Max splitting ratio

1:128

Dimension (L*W*H)

442mm*320mm*43.6mm

Net weight (single power)

4.8kg

Gross weight (single power)

6.4kg

Power Consumption

85W

Working Temperature

0°C ~+50°C

Storage Temperature

-40~+85°C

Relative Humidity

5~90% (non-conditioning)

Management Ports

1*10/100/1000BASE-T out-band port, 1*CONSOLE port, 1*USB2.0, 1*Type-C   USB (for console)

Max. Transmission Distance

20KM

Max. Speed

Upstream 1.244Gbps, Downstream 2.488Gbps

Wavelength

TX 1490nm, RX 1310nm

Connector

SC/UPC

Fiber Type

9/125μm SMF

TX Power

+4.5~+10dBm

Rx Sensitivity

≤-30dBm

Saturation Optical Power

-12dBm

Management Mode

TR069 ACS, WEB, SNMP, Telnet, CLI

Software Features

Management

SNMP, Telnet, CLI, WEB, SSH

Port Status monitoring and configuration management

Online ONT configuration and management

User management

Alarm management

Layer2 Switch

32K Mac address

Support 4096 VLANs

Support port VLAN and protocol VLAN

Support VLAN tag/Un-tag, VLAN transparent transmission

Support VLAN translation and QinQ

Support storm control based on port

Support port isolation

Support port rate limitation

Support 802.1D and 802.1W

Support LACP

QoS based on port, VID, TOS and MAC address

Access control list

IEEE802.x flow control

Port stability statistic and monitoring

L2 Multicast

IGMP snooping

2K IP Multicast Groups;

DHCP

DHCP server, DHCP relay, DHCP snooping

DHCP option82

Layer 3 Protocols

ARP proxy

4096 hardware Host Routes
