| WI-FI |
| Wi-Fi Standards |
IEEE 802.11a/b/g/n/ac Wave 2 |
| Supported Rates |
• 802.11ac: 6.5 to 1733 Mbps
• 802.11n: 6.5 to 600Mbps
• 802.11a/g: 6 to 54 Mbps
• 802.11b: 1 to 11 Mbps |
| Supported Channels |
• 2.4GHz: 1-13
• 5GHz: 36-64, 100-144, 149-165 |
| MIMO |
4x4 |
| Spatial Streams |
4 streams SU/MU |
| Channelization |
20, 40, 80, 160MHz |
| Security |
• WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i, Dynamic PSK
• WIPS/WIDS |
| Other Wi-Fi Features |
• WMM, Power Save, TxBF, LDPC, STBC, 802.11r/k/v
• Hotspot
• Hotspot 2.0
• Captive Portal
• WISPr |
| RF |
| Antenna Type |
• BeamFlex+ adaptive antennas
• Polarization: 2 Vertical & 2 Horizontal |
| Antenna Gain (max) |
3dBi for both 2.4GHz and 5GHz |
| Peak Transmit Power (aggregate across MIMO chains) |
• 2.4GHz: 28dBm
• 5GHz: 30dBm |
| Minimum Receive Sensitivity |
• 2.4GHz: -102dBm
• 5GHz: -96dBm |
| Frequency Bands |
• ISM 2.4-2.484GHz
• U-NII-1 5.15-5.25GHz
• U-NII-2A 5.25-5.35GHz
• U-NII-2C 5.47-5.725GHz
• U-NII-3 5.725-5.85GHz |
| PERFORMANCE AND CAPACITY |
| Peak PHY Rates |
2.4GHz: 600 Mbps |
| Client Capacity |
Up to 512 clients per AP |
| SSID |
Up to 32 per AP |
| RUCKUS RADIO MANAGEMENT |
| Antenna Optimization |
• BeamFlex+
• Polarization Diversity with Maximal Ratio Combining (PD-MRC) |
| Wi-Fi Channel Management |
• ChannelFly
• Background Scan Based |
| Client Density Management |
• Adaptive Band Balancing
• Client Load Balancing
• Airtime Fairness
• Airtime-based WLAN Prioritization |
| Mobility |
SmartRoam |
| Queuing and Scheduling |
SmartCast |
| Diagnostic Tools |
• Spectrum Analysis
• SpeedFlex |
| NETWORKING |
| Controller Platform Support |
• SmartZone |
| IP |
IPv4, IPv6 |
| Mesh |
SmartMesh™ wireless meshing technology. Selfhealing Mesh |
| VLAN |
• 802.1Q (1 per BSSID or dynamic per use based on RADIUS)
• VLAN Pooling
• Port-based |
| 802.1x |
Wired & wireless authenticator & Supplicant |
| Tunnel |
RuckusGRE, softGRE |
| Policy Management Tools |
• Application Visibility and Control
• Access Control Lists
• Device Fingerprinting |
| PHYSICAL INTERFACES |
| Ethernet |
1 x 1GbE port PoE-out (802.3at), RJ-45 |
| USB |
1 USB 2.0 port, Type A |
| Fiber |
SFP, 1Gbps, EPON, 1000BASE-lx |
| Cable Modem |
Type F, DOCSIS 3.1 |
| PHYSICAL CHARACTERISTICS |
| Physical Size |
• 44.2 (L) x 24.98 (W) x 15.43 (H) cm
• 17.4 (L) x 9.84 (W) x 6.07 (H) in |
| Weight |
7.15kg (15.73lbs) |
| Ingress Protection |
IP-67. ASTM B117 (Salt Spray) |
| Mounting |
Strand |
| Operating Temperature |
-40ºC (-40ºF) to 65ºC (149ºF) |
| Operating Humidity |
Up to 95%, non-condensing |
| POWER |
| AC Input (over Coax) |
40V to 90V RMS 50/60Hz Quasi-Square Wave |
| Maximum Current Draw |
• Max Current
• Draw: 1.75A @50V |
| Power Consumption |
• Min: 56.7W
• Typical: 67.8W
• Max: 93.7W |
| CERTIFICATIONS AND COMPLIANCE |
| Wi-Fi Alliance |
• Wi-Fi CERTIFIED™ a, b, g, n, ac
• Passpoint®, Vantage |
| Standards Compliance |
• EN 60950-1 Safety
• EN 60950-22 Safety
• EN 61000-4-2/3/5 Immunity
• EN 50121-1 Railway EMC
• EN 50121-4 Railway Immunity
• IEC 61373 Railway Shock & Vibration
• EN 62311 Human Safety/RF Exposure
• WEEE & RoHS
• ISTA 2A Transportation |
| OTHER RADIO TECHNOLOGIES |
| GPS |
GPS, GLONASS |
