| WI-FI |
| Wi-Fi Standards |
• IEEE 802/11a/b/g/n/ac/ax |
| Supported Rates |
• 802.11ax: 4 to 2400 Mbps
• 802.11ac: 6.5 to 1732 Mbps
• 802.11n: 6.5 to 600 Mbps
• 802.11a/g: 6 to 54 Mbps
• 802.11b: 1 to 11 Mbps
|
| Supported Channels |
• 2.4GHz: 1-13
• 5GHz: 36-64, 100-144, 149-165 |
| MIMO |
• 4x4 SU-MIMO
• 4x4 MU-MIMO |
| Spatial Streams |
• 4 for both SU-MIMO & MU-MIMO |
| Radio Chains and Streams |
• 4x4:4 |
| Channelization |
• 20, 40, 80, 160MHz |
| Security |
• WPA-PSK, WPA-TKIP, WPA2 AES, WPA3, 802.11i, Dynamic PSK, OWE
• WIPS/WIDS |
| Other Wi-Fi Features |
• WMM, Power Save, Tx Beamforming, LDPC, STBC, 802.11r/k/v
• Hotspot
• Hotspot 2.0
• Captive Portal
• WISPr |
| RF |
| Antenna Type |
• BeamFlex+ adaptive antennas with polarization diversity
• Adaptive antenna that provides 4,000+ unique antenna patterns per band |
| Antenna Gain (max) |
• Up to 3dBi |
| Peak Transmit Power (Tx port/chain + Combining gain) |
• 2.4GHz: 26dBm
• 5GHz: 28 dBm |
| Frequency Bands |
• ISM (2.4-2.484GHz)
• U-NII-1 (5.15-5.25GHz)
• U-NII-2A (5.25-5.35GHz)
• U-NII-2C (5.47-5.725GHz)
• U-NII-3 (5.725-5.85GHz) |
| PERFORMANCE AND CAPACITY |
| Peak PHY Rates |
• 2.4GHz: 1148 Mbps
• 5GHz: 2400 Mbps |
| Client Capacity |
• Up to 1024 clients per AP |
| RUCKUS RADIO MANAGEMENT |
| Antenna Optimization |
• BeamFlex+
• Polarization Diversity with Maximal Ratio Combining (PD-MRC) |
| Wi-Fi Channel Management |
• ChannelFly
• Background Scan Based |
| Client Density Management |
• Adaptive Band Balancing
• Client Load Balancing
• Airtime Fairness
• Airtime-based WLAN Prioritization |
| SmartCast Quality of Service |
• QoS-based scheduling
• Directed Multicast
• L2/L3/L4 ACLs |
| Mobility |
SmartRoam |
| Diagnostic Tools |
• Spectrum Analysis
• SpeedFlex |
| NETWORKING |
| Controller Platform Support |
• SmartZone
• ZoneDirector
• Standalone |
| Mesh |
SmartMesh™ wireless meshing technology. Self-healing Mesh |
| IP |
IPv4, IPv6, dual-stack |
| VLAN |
• 802.1Q (1 per BSSID or dynamic per user based on RADIUS)
• VLAN Pooling
• Port-based |
| 802.1x |
Authenticator & Supplicant |
| Tunnel |
L2TP, GRE, Soft-GRE |
| Policy Management Tools |
• Application Recognition and Control
• Access Control Lists
• Device Fingerprinting
• Rate Limiting |
| IoT Capbale |
• Yes |
| PHYSICAL INTERFACES |
| Ethernet |
• 1x2.5 Gbps, 1 x 10/100/1000 Mbps ports, RJ-45
• LLDP |
| Fiber |
• SFP, 1Gbps, SFP+ 10 Gbps |
| USB |
• 1 USB 2.0 port, Type A |
| PHYSICAL CHARACTERISTICS |
| Physical Size |
• 34.64cm (L), 24.06cm (W), 10.17cm (H)
• 13.64in (L) x 9.47in (W) x 4.0in (H) |
| Weight |
• 2.84 kg
• 6.27 lbs |
| Mounting |
• Pole Mount |
| Operating Temperature |
• -40°C (-40°F) to 65°C (145°F) |
| Operating Humidity |
• Up to 95%, non-condensing |
| Wind Survivabiity |
• Up to 266km/h (165mph) |
| POWER |
| AC Power |
• 64.6W (SFP+ Backhaul)
• 63.7W (Ethernet Backhaul) |
| 802.3bt Class 7 (Maximum Functionality With PSE Out) |
• 57W |
| 802.3bt Class 5 (Reduced Functionality With PSE Out Disabled) |
• 31W |
| 802.3at (Reduced Functionality Without USB) |
• 24.2W |
| Idle |
• 10.75W |
| CERTIFICATIONS AND COMPLIANCE |
| Wi-Fi Alliance |
• Wi-Fi CERTIFIED™ a, b, g, n, ac, ax
• Passpoint®, Vantage |
| Standards Compliance |
• EN 60950-1 Safety
• EN 60601-1-2 Medical
• EN 61000-4-2/3/5 Immunity
• EN 50121-1 Railway EMC
• EN 50121-4 Railway Immunity
• IEC 61373 Railway Shock & Vibration
• UL 2043 Plenum
• EN 62311 Human Safety/RF Exposure
• WEEE & RoHS
• ISTA 2A Transportation |
