Switch Cisco C9500-48Y4C-A 48-port 25G switch, NW Adv. License
Switch Cisco C9500-48Y4C-A Catalyst 9500 Series high performance 48-port 25G switch, 4x 100G Uplink, Network Advantage License
- Danh mục sản phẩm Switch Cisco 9500 Series
- Scenario
- Switch Type
- Số Cổng
- Routing/Switching
- Downlink Ports
- Uplink Ports
- Management
- Configurations
- Features
Switch Cisco C9500-48Y4C-A
| Cisco Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Thiết bị chuyển mạch Cisco C9500-48Y4C-A là thế hệ tiếp theo của bộ chuyển mạch lớp Core và lớp doanh nghiệp, hỗ trợ khả năng lập trình và khả năng phục vụ ưu việt. Dựa trên kiến trúc CPU x86, C9500-48Y4C-A là nền tảng chuyển đổi doanh nghiệp cốt lõi và tổng hợp cố định được xây dựng trên nền tảng chuyên dụng của Cisco, được xây dựng để bảo mật, IoT và đám mây. Switch Cisco C9500-48Y4C-A đi kèm với CPU 4 nhân x86, 2,4 GHz, bộ nhớ DDR4 16 GB và bộ nhớ trong 16 GB.
Switch Cisco C9500-48Y4C-A hỗ trợ các công nghệ định tuyến và dịch vụ cơ sở hạ tầng mới nhất của Cisco (nưu Multiprotocol Label Switching [MPLS] Layer 2 và Layer 3 VPNs, Multicast VPN [MVPN], và Network Address Translation [NAT]); Cisco Software-Defined Access capabilities (như host tracking database, cross-domain connectivity, VPN Routing và Forwarding [VRF]-aware Locator/ID Separation Protocol [LISP]); hệ thống ảo hóa mạng với công nghệ ảo hóa Cisco StackWise®. Switch Cisco C9500-48Y4C-A cũng hỗ trợ các khả năng có sẵn cao như patching, Graceful Insertion and Removal (GIR), Cisco Nonstop Forwarding with Stateful Switchover (NSF/SSO), nguồn và quạt có thể thay thế và dự phòng.
Thông số kỹ thuật Switch Cisco C9500-48Y4C-A
| Performance specifications | |
| ASIC | UADP 3.0 |
| Switching capacity | Up to 3.2 Tbps full duplex |
| Forwarding rate | Up to 1 Bpps |
| Total number of MAC addresses | Up to 80,000 |
| Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) |
Up to 212,000 indirect + direct* Up to 90,000 host* |
| Total number of IPv6 routes |
Up to 212,000 indirect + direct* Up to 90,000 host* |
| Multicast scale | Up to 32,000 (IPv4 or IPv6) |
| QoS ACL scale | Up to 16000 |
| Security ACL scale | Up to 27000 |
| FNF entries | Up to 96,000 |
| DRAM | 16 GB |
| Flash | 16 GB |
| VLAN IDs | 4000 |
| Total Switched Virtual Interfaces (SVIs) | 4000 |
| Jumbo frame | 9216 bytes |
| Dimensions, physical specifications, weight, and MTBF | |
| Dimensions (H x W x D) | 1.73 x 17.5 x 18.0 in |
| Rack Units (RU) | 1 RU |
| Chassis with 2 power supplies and built-In fan | 21.96 lb (9.96 kg) |
| Input voltage | 90 to 264 VAC |
| Operating temperature | 32° to 104°F (0° to 40°C) |
| Storage temperature | -4° to 149°F (-20° to 65°C) |
| Relative humidity operating and nonoperating noncondensing |
Ambient (noncondensing) operating: 5% to 90% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
| Altitude | Operation up to 13,000 feet at 40°C |
| MTBF (hours) | 316,960 |
| Standards |
IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.3ae for 10G SKU IEEE 802.3ae, IEEE 802.3ba on the 40G SKU IEEE 802.1x-Rev IEEE 802.3ad IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS prioritization IEEE 802.1Q VLAN IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification RMON I and II standards SNMPv1, SNMPv2c, and SNMPv3 |
| Safety certifications |
- IEC 60950-1 plus Am1, Am2 Am9, Am10, Am11, Am12 and all deviations and differences
- AS/NZS 60950.1.2011
- CAN/CSA-C22.2 No. 60950-1-07
- GB 4943-95
- EN 60950-1; 2006 plus Am1, Am 2, Am9, Am10, Am11, Am12 and all deviations and differences
- NOM-019-SCFI-1998
- UL 60950-1, Second Edition
|
| EMI and EMC compliance |
47 CFR Part 15 Class A CNS13438: 2006 Class A EN 300 386 V1.6.1 EN61000-3-2: 2014 EN61000-3-3: 2013 ICES-003 Issue 6: 2016 Class A KN 32: 2015 Class A TCVN 7189: 2009 Class A EN 55032:2012/ AC:2013 Class A EN 55032:2015 Class A CISPR 32 Edition 2 Class A V-2/2015.04 Class A V-3/2015.04 Class A CISPR24: 2010 + A1: 2015 EN 300 386 V1.6.1 EN55024: 2010 + A1: 2015 KN35: 2015 TCVN 7317: 2003 |
Các tính năng trên Switch Cisco C9500-48Y4C-A
| Switch fundamentals | Layer 2, Routed Access (RIP, EIGRP Stub, OSPF - 1000 routes),PBR, PIM Stub Multicast (1000 routes)), PVLAN, VRRP, PBR, CDP, QoS, FHS, 802.1x, Macsec-128, CoPP, SXP, IP SLA Responder, SSO |
| Advanced switch capabilities and scale | BGP, EIGRP, HSRP, IS-IS, BSR, MSDP, PIM-BIDIR, IP SLA, OSPF |
| Network segmentation | VRF, VXLAN, LISP, SGT, MPLS, mVPN |
| Automation | Netconf, Restconf, gRPC, YANG, PnP Agent, ZTP/Open PnP, GuestShell (On-Box Python) |
| Telemetry and visibility | Model-driven telemetry, sampled NetFlow, SPAN, RSPAN |
| High availability and resiliency | NSF, GIR, ISSU/EFSU, StackWise Virtual |
| IOT integration | AVB, PTP, CoAP |
| Security | MACsec-256 |
| Optimized network deployments | DNA Service for Bonjour |
| Advanced telemetry and visibility | Full Flexible NetFlow, EEM |
| Optimized telemetry a visibility | ERSPAN, AVC (NBAR2), App Hosting (in Containers/VMs), Wireshark |
| Advanced security | Encrypted Traffic Analytics (ETA) |
| Element management | Patch Management |
| SD-Access | Policy-based Automation & Assurance for Wired & Wireless |
| Day 0 network bring-up automation | Cisco Network Plug-n-Play application, network settings, device credentials, LAN Automation, Host onboarding |
| Element management | Discovery, inventory, topology, software image, licensing, and configuration management |
| Basic Assurance | Health Dashboards – Network, Client, Application; Switch & Wired Client Health Monitoring |
| Network assurance and analytics | Global Insights, Trends, Compliance, Custom Reports; Switch 360, Wired Client 360; Fabric and Non-Fabric Insights; App Health, App 360, App Performance (Loss, Latency, Jitter) |
Bạn đang cần tư vấn về sản phẩm: #C9500-48Y4C-A ?
