Thiết bị mạng Switch Cisco Nexus N3K-C3548P-10G 48 SFP+
Switch cisco Nexus N3K-C3548P-10G Cisco Nexus® 3000 Series, là sản phẩm được thiết kế để đơn giản hóa kiến trúc và và hoạt động tại các trung tâm dữ liệu.
Thông số kỹ thuật :
|
Mode
|
Normal Mode
|
Warp Mode
|
|
Hardware tables and scalability
|
Number of MAC addresses
|
64,000
|
8000
|
|
Number of IPv4 unicast routes
|
24,000
|
4000
|
|
Number of IPv4 hosts
|
64,000
|
8000
|
|
Number of IPv4 multicast routes
|
8000
|
8000
|
|
Number of VLANS
|
4096
|
|
Number of ACL entries
|
4096
|
|
Number of spanning-tree instances
|
Rapid Spanning Tree Protocol (RSTP): 512
Multiple Spanning Tree (MST) Protocol: 64
|
|
Number of EtherChannels
|
24
|
|
Number of ports per EtherChannel
|
24
|
|
Buffer size
|
6 MB shared among 16 ports; 18 MB total
|
|
Boot flash memory
|
2 GB
|
|
Power
|
Number of power supplies
|
2 (redundant)
|
|
Power supply types
|
- AC (forward and reversed airflow)
- DC (forward and reversed airflow)
|
|
Input voltage
|
100 to 240 VAC
|
|
Frequency
|
50 to 60 Hz
|
|
Power supply efficiency
|
89 to 91% at 220V
|
|
Cooling
|
Forward and reversed airflow schemes
- Forward airflow:Port-side exhaust (air enters through fan tray and power supplies and exits through ports)
- Reversed airflow: Port-side intake (air enters through ports and exits through fan tray and power supplies)
Four individual, hot-swappable fans (3+1 redundant)
|
|
Environment
|
Dimensions (height x width x depth)
|
1.72 x 17.3 x 18.38 in. (4.36 x 43.9 x 46.7 cm)
|
|
Weight
|
17.4 lb (7.9 kg)
|
|
Operating temperature
|
32 to 104° F (0 to 40°C)
|
|
Storage temperature
|
-40 to 158° F (-40 to 70°C)
|
|
Relative humidity (operating)
|
- 10 to 85% noncondensing
- Up to 5 days at maximum (85%) humidity
- Recommend ASHRAE data center environment
|
|
Relative humidity (nonoperating)
|
5 to 95% noncondensing
|
|
Altitude
|
0 to 10,000 ft (0 to 3000m)
|
|
Mean time between failure (MTBF)
|
317,030 hours
|
Các loại module quang Cisco sử dụng cho switch cisco N3K-C3548P-10G:
Module quang Cisco 10G
|
SFP-10G-SR
|
10GBASE-SR SFP+ module (MMF)
|
|
SFP-10G-LR
|
10GBASE-LR SFP+ module (single-mode fiber [SMF])
|
|
SFP-10G-ER
|
Cisco 10GBASE-ER SFP+ module for SMF
|
|
DWDM-SFP10G-*
|
10GBASE-DWDM modules (multiple varieties)
|
|
SFP-H10GB-CU1M
|
10GBASE-CU SFP+ cable, 1m (Twinax cable)
|
|
SFP-H10GB-CU3M
|
10GBASE-CU SFP+ cable, 3m (Twinax cable)
|
|
SFP-H10GB-CU5M
|
10GBASE-CU SFP+ cable, 5m (Twinax cable)
|
|
SFP-H10GB-ACU7M
|
Active Twinax cable assembly, 7m
|
|
SFP-H10GB-ACU10M
|
Active Twinax cable assembly, 10m
|
Module quang cisco Gigabit ethernet
|
GLC-T
|
1000BASE-T SFP
|
|
GLC-SX-MM
|
GE SFP, LC connector SX transceiver (MMF)
|
|
GLC-SX-MMD
|
1000BASE-SX SFP transceiver module, MMF, 850 nm, DOM
|
|
GLC-LH-SM
|
GE SFP, LC connector LX and LH transceiver
|
|
GLC-LH-SMD
|
1000BASE-LX/LH SFP transceiver module, MMF and SMF, 1310 nm, DOM
|
Các loại nguồn sử dụng cho switch cisco N3K-C3548P-10G:
|
N2200-PAC-400W
|
N2K/3K 400W AC Power Supply, Forward airflow (port side exhaust)
|
|
N2200-PAC-400W-B
|
N2K/3K 400W AC Power Supply, Reversed airflow (port side intake)
|
|
N2200-PDC-400W
|
N2K/3K 400W DC Power Supply, Forward airflow (port side exhaust)
|
|
N3K-PDC-350W-B
|
N2K/3K 350W DC Power Supply, Reversed airflow (port side intake)
|
Các loại Fan sử dụng cho switch cisco N3K-C3548P-10G:
|
NXA-FAN-30CFM-F
|
N2K/3K Individual Fan, Forward airflow (port side exhaust)
|
|
NXA-FAN-30CFM-B
|
N2K/3K Individual Fan, Reversed airflow (port side intake)
|
License sử dụng cho switch cisco N3K-C3548P-10G:
|
N3548-BAS1K9
|
Nexus 3000 Layer 3 Base License
|
|
N3548-LAN1K9
|
Nexus 3548 Layer 3 LAN Enterprise License (Requires N3K-BAS1K9 License)
|
|
N3548-ALGK9
|
Nexus 3500 Algo Boost License
|
|
NDB-FX-SWT-K9
|
License for Tap/SPAN aggregation using Cisco Nexus Data Broker
|
|
N3548-24P-UPG=
|
Nexus 3524 additional 24 port license
|
