| Datasheet XE5-8X00A00-RoW |
| Specifications |
| Radios |
Two: 4x4 5/6 GHz 802.11a/n/ac/ax, SW configurable to 5 or 6GHz operation
Two: 4x4 5 GHz 802.11a/n/ac/ax, SW configurable to one 8x8 radio
One: 4x4 2.4 GHz 802.11 b/g/n/ax
BLE 4.1
|
| Wi-Fi |
802.11 a/b/g/n/ac Wave 2/ax |
| SSID Security |
WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), WEP, Open |
| Ports |
2 x IEEE 10/100/1000/2500/5000 Mbps Ethernet
1 x USB 3.0
|
| Antenna |
6 GHz: 5.82 dBi, Omni
5 GHz: 5.61 dBi, Omni
2.4 GHz: 4.58 dBi, Omni
|
| Max EIRP |
6 GHz: 30 dBm
5 GHz: 33 dBm
2.4 GHz: 30 dBm
|
| Power |
Max 59W 802.3bt powered device
|
| Dimensions |
300 mm x 300 x 58 mm (without bracket) (11.81 in x 11.81 x 2.28 in ) |
| Weight |
1.8 kg (3.97 lbs) |
| Security |
Kensington lock slot |
| LEDs |
Multi-color status LEDs |
| Ambient Operating Temperature |
0ºC to 50ºC (32ºF to 122ºF) |
| Storage Temperature |
-40ºC to 70ºC (-40ºF to 158ºF) |
| Humidity |
95% RH non-condensing |
| MTBF |
668,759 hours 25ºC
314,145 hours at 50ºC
|
| Mount Options |
Wall or ceiling, T-bar with included locking bracket, ceiling tile plate |
| Certifications (Compliance) |
FCC, IC, CE, EN 60601-1-2, EN 60950-1, IEC 62368-1 Safety, EN 60601-1-2 Medical EMC, EN 61000-4-2/3/5 Immunity, EN 50121-1 Railway EMC, EN 50121-4 Railway EMC, IEC 61373 Railway Shock & Vibration, UL 2043 Plenum, EN 62311 Human Safety/RF Exposure, WEEE & RoHS |
| WLAN |
2,500 clients, 16 SSIDs WPA-TKIP, WPA2 AES, WPA3 SAE, WPA3 Enterprise, 802.1x, 802.11w PMF |
| Authentication Encryption |
Hotspot 2.0 802. EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, EAP-TLS, MAC authentication to local database or external RADI |
| Subscriber QoS |
WMM |
| Fast Roaming |
802.11r, OKC, assisted roaming |
