FS-3032D Fortinet FortiSwitch 3032D 32x 40 GE QSFP+ slots

Phân phối Fortinet FS-3032D FortiSwitch 3032D FortiGate switch Layer 2 và layer 3 controller compatible switch with 32x 40 GE QSFP+ slots, Dual AC power supplies, chính hãng giá tốt, FortiSwitch FS-3032D datasheet
Mã sản phẩm: FS-3032D
Tình trạng: Còn hàng
Check Giá List

FS-3032D Fortinet FortiSwitch 3032D 32x 40 GE QSFP+ slots

Fortinet SKU        : FS-3032D
Fortinet Product  : FortiSwitch 3032D
List Price              : $17,995.00
Bảo hành             : 12 tháng
Made In               : China
Stock                    : Liên hệ

Mô tả tổng quan

FortiSwitch FS-3032D cung cấp các giải pháp Ethernet an toàn, đơn giản, khả năng mở rộng với thông lượng vượt trội, khả năng phục hồi và khả năng mở rộng cho các tổ chức có yêu cầu mạng hiệu suất cao.

View Datasheet FS-3032D

FortiSwitch FS-3032D là thiết bị lý tưởng cho các Server, Firewall, cũng như triển khai các mạng Core hoặc triển khai mạng doanh nghiệp, ở đó yêu cầu hiệu suất cao 10GE

Fortinet FS-3032D được thiết kế để đáp ứng nhu cầu của các trung tâm dữ liệu chuyên sâu đòi hỏi băng thông cao và mạng doanh nghiệp ngày nay. Fortinet FS-3032D mang lại hiệu suất cao với tổng chi phí sở hữu thấp

FS-3032D Fortinet FortiSwitch 3032D 32x 40 GE QSFP+ slots

Thông số kỹ thuật FortiSwitch FS-3032D

Hardware Specifications
Total Network Interfaces 32x 40 GE QSFP+ ports
10/100/1000 Service Ports 1
RJ-45 Serial Console Port 1
Form Factor 1 RU Rack-Mount Appliance
System Specifications
Switching Capacity (Duplex) 2560 Gbps
Packets Per Second (Duplex) 3840 Mpps
MAC Address Storage 288 K
Network Latency < 800ns
VLANs Supported 4 K
IPv4/IPv6 Dual Stack Routing Ready Hardware Yes
Link Aggregation Group Size Up to 24
Total Link Aggregation Groups Up to number of ports
Queues/Port 8
Packet Buffers 12 MB
DRAM 2 GB
NAND 128 MB
Dimensions
Height x Depth x Width (inches) 1.71 x 18.11 x 17.26
Height x Depth x Width (mm) 43.5 x 460 x 438.5
Weight 19.40 lbs (8.8 kg)
Environment
Power Required 100–240V AC, 50–60 Hz
Power Consumption (Maximum) up to 387 W
Power Supply Dual hot swappable AC
Heat Dissipation 656.83 BTU/h
Operating Temperature 32–104°F (0–40°C)
Storage Temperature -13–158°F (-25–70°C)
Humidity 10–90% RH non-condensing
Mean Time Between Failures > 10 years
Certification and Compliance FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Các tính năng trên Switch Fortinet FS-3032D

Management and Configuration
  • Auto Discovery of Multiple Switches
  • Number of Managed Switches per FortiGate: 8 to 256 Depending on FortiGate Model (Please refer to admin-guide) FortiLink Stacking (Auto Inter-Switch Links)
  • Software Upgrade of Switches
  • Centralized VLAN Configuration
  • Switch POE Control
  • Link Aggregation Configuration
  • Spanning Tree Yes LLDP/MED
  • IGMP Snooping
  • L3 Routing and Services
  • Policy-Based Routing
  • Virtual Domain
Security and Visibility
  • 802.1x Authentication (Port-based, MAC-Based, MAB)
  • Syslog Collection
  • DHCP Snooping
  • Device Detection
  • MAC Black/While Listing
  • Policy Control of Users and Devices
UTM Features
  • Firewall
  • IPC, AV, Application Control, Botnet
High Availability
  • Support FortiLink FortiGate in HA Cluster
  • LAG support for FortiLink Connection
  • Active-Active Split LAG from FortiGate to FortiSwitches for Advanced Redundancy
Layer 2
  • Jumbo Frames
  • Auto-negotiation for port speed and duplex
  • IEEE 802.1D MAC Bridging/STP
  • IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
  • IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
  • STP Root Guard
  • Edge Port / Port Fast
  • IEEE 802.1Q VLAN Tagging
  • Private VLAN
  • IEEE 802.3ad Link Aggregation with LACP
  • Unicast/Multicast traffic balance over trunking port (dst-ip, dst-mac, src-dst-ip, src-dst-mac, src-ip, src-mac)
  • IEEE 802.1AX Link Aggregation
  • Spanning Tree Instances (MSTP/CST) 15/1 15/1 15/1 15/1 IEEE 802.3x Flow Control and Back-pressure
  • IEEE 802.1Qbb Priority-based Flow Control
  •  IEEE 802.3z 1000Base-SX/LX
  • IEEE 802.3ab 1000Base-T
  • IEEE 802.3ae 10 Gigabit Ethernet
  • IEEE 802.3 CSMA/CD Access Method and Physical Layer Specifications
  • Storm Control
  • MAC, IP, Ethertype-based VLANs
  • Virtual-Wire
  • Split Port (QSFP+ breakout to 4xSFP+)
Layer 3
  • Static Routing (Hardware-based)
  • Routing Entries 16K
  • L3 Host Entries 16K
  • Dynamic Routing Protocols: OSPFv2, RIPv2, VRRP, BGP, ISIS
  • Multicast Protocols PIM-SSM
  • ECMP
  • Bidirectional Forwarding Detection (BFD)
  • DHCP Relay
  • IGMP Snooping
Security and Visibility
  • Port Mirroring
  • Admin Authentication Via RFC 2865 RADIUS
  • IEEE 802.1x authentication Port-based
  • IEEE 802.1x Authentication MAC-based
  • IEEE 802.1x Guest and Fallback VLAN
  • IEEE 802.1x MAC Access Bypass (MAB)
  • IEEE 802.1x Dynamic VLAN Assignment
  • MAC-IP Binding
  • sFlow
  • ACL: 2K entries
  • IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
  • IEEE 802.1ab LLDP-MED
  • DHCP-Snooping
  • Dynamic ARP Inspection
  • Sticky MAC
High Availability
  • Multi-Chassis Link Aggregation (MCLAG)
Quality of Service
  • IEEE 802.1p Based Priority Queuing
  • IP TOS/DSCP Based Priority Queuing
Management
  • IPv4 and IPv6 Management
  • Telnet / SSH
  • HTTP / HTTPS
  • SNMP v1/v2c/v3
  • SNTP
  • Standard CLI and web GUI interface
  • Software download/upload: TFTP/FTP/GUI
  • Managed from FortiGate
  • Support for HTTP REST APIs for Configuration and Monitoring
Additional RFC and MIB Support
  • RFC 2571 Architecture for Describing SNMP Framework
  • DHCP Client
  • RFC 854 Telnet Server
  • RFC 2865 RADIUS
  • RFC 1643 Ethernet-like Interface MIB
  • RFC 1213 MIB-II
  • RFC 1354 IP Forwarding Table MIB
  • RFC 2572 SNMP Message Processing and Dispatching
  • RFC 1573 SNMP MIB II
  • RFC 1157 SNMPv1/v2c
  • RFC 2030 SNTP

License cho Switch Fortinet FS-3032D

FortiSwitch Advanced Features License FS-SW-LIC-3000 SW License for FS-3000 Series Switches to activate Advanced Features.

Các loại Module quang sử dụng cho Switch Fortinet FS-3032D

40 GE QSFP+ transceivers, short range

FG-TRAN-QSFP+SR

40 GE QSFP+ transceivers, short range for all systems with QSFP+ slots

40 GE QSFP+ transceivers, short range, BiDi

FG-TRAN-QSFP+SR-BIDI

40 GE QSFP+ transceivers, short range BiDi for systems with QSFP+ slots

40 GE QSFP+ transceivers, long range

FG-TRAN-QSFP+LR

40 GE QSFP+ transceivers, long range for all systems with QSFP+ slots

40 GE QSFP+ to 4x 10 GE SFP+ optical breakout, 1 meter

FG-TRAN-QSFP-4XSFP

40 GE QSFP+ parallel breakout MPO to 4x LC connectors, 1 m reach, transceivers not included

40 GE QSFP+ to 4x 10 GE SFP+ optical breakout, 5 meter

FG-TRAN-QSFP-4SFP-5

40 GE QSFP+ parallel breakout MPO to 4x LC connectors, 5 m reach, transceivers not included

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+1

40 GE QSFP+ passive direct attach cable, 1 m for systems with QSFP+ slots

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+3

40 GE QSFP+ passive direct attach cable, 3 m for systems with QSFP+ slots

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+5

40 GE QSFP+ passive direct attach cable, 5 m for systems with QSFP+ slots
