Cisco SF95D-16 SMB 95 Series Unmanaged 16 Ports 10/100 Desktop Switch

Cisco SF95D-16 SMB 95 Series Unmanaged 16 Ports 10/100 Desktop Switch

bình luận

Thiết bị mạng Cisco SF95D-16 SMB 95 Series Unmanaged 16 Ports 10/100 Mbps Desktop Switch

Mã sản phẩm: SF95D-16

Tình trạng: Còn hàng

Giá bán liên hệ

Check Giá List

Danh mục sản phẩm Switch Cisco Small Business
Scenario
- Small Business
Switch Type
- Fixed Port
Số Cổng
- 16-20 Cổng
Routing/Switching
Downlink Ports
- 100 Mbps RJ45
Uplink Ports
Management
- Unmanaged
Configurations
- Fanless
Features

Chi tiết sản phẩm

Cisco SF95D-16 SMB 95 Series Unmanaged 16 Ports 10/100 Desktop Switch

Cisco Part Number : SF95D-16
Bảo hành : 12 tháng
Made In : Asia

Switch Cisco SF95D-16 thuộc Cisco Small Business 95 series. Switch Cisco SF95D-16 được thiết kế để hoạt động ở layer 2 trong mô hình OSI. Switch Cisco SF95D-16 cung cấp 16 10/100 ports cho các kết nối LAN tại các doanh nghiệp vừa và nhỏ.

View Datasheet SF95D-16

Switch cisco SF95D-16 để kết nối các máy tính, máy in, camera hoăc các thiết bị wifi trong 1 phòng ban, trong các doanh nghiệp nhỏ với số lượng user ít... hoặc sử dụng để mở rộng mạng LAN trong các doanh nghiệp.

Thông số kỹ thuật Switch Cisco SF95D-16

Specifications	Description
Standards	IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet
Cabling type	Category 5e or better
LED indicators	System/PWR, link/activity, 100M, cable diagnostics, loop detection, gigabit, mini-GBIC* *if present
Physical Interfaces
Ports	10/100/1000 Ethernet, power port for AC adapter or power cord
Power supply	DC 12V, 1.0A
Lock slot	Slot for Kensington lock
Physical Specifications
Physical dimensions (W x D x H)	160x43.5x90 mm
Weight	1.03 lb. (0.46 kg)
Ports	16 RJ-45 connectors for 10BASE-T/100BASE-TX All units: automatic medium dependent interface (MDI) and MDI crossover (MDI-X); auto-negotiated port for connecting 10-, 100-, 1000-Mbps devices
Performance
Switching capacity	3.2 Gbps
Forwarding capacity	1.4 mpps
Capabilities
Head-of-line (HOL) blocking	HOL blocking prevention
Jumbo frame	9216 bytes
Quality of service (QoS)	802.1p priority based, hardware queues, priority queuing and weighted round-robin (WRR)
Loop detection	Helps discover loops in the network to avoid broadcast storms
Cable diagnostics	Quickly identify and troubleshoot network cable faults and/or shorts
Mounting and Physical Security
Mounting options	Desktop or rack mount
Physical security lock	Kensington lock slot
Environmental
Compliance/certifications	UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B* *select models
Operating temperature	32° to 104°F (0° to 40°C)
Storage temperature	-4° to 158°F (-20° to 70°C)
Operating humidity	10% to 90%, relative, noncondensing
Storage humidity	5% to 90%, relative, noncondensing
Package Contents	Cisco 95 Series switch Power cord/power adapter Mounting hardware
Minimum Requirements	- Devices supporting 802.3 Ethernet, 802.u Faster Ethernet, or 802.3ab Gigabit Ethernet - Cat5 or better Ethernet cable - Network interface card for each computer
