Cisco Model : SG500X-24
Product ID Number: SG500X-24-K9
Bảo hành : 12 tháng
Made In : Chính hãng
Switch Cisco SG500X-24 thuộc dòng sản phẩm Cisco small business 500 series.Thiết bị mạng switch Cisco SG500X-24 được thiết kế để phù hợp ở cả 3 lớp mạng.
Switch Cisco SG500X-24 cung cấp 24 10/100/1000 ports, 4*10 GE SFP+ (2*10 GE+ 2*10GE/5GE-Stacking Combo) mang đến hệ thống mạng phù hợpp doanh nghiệp vừa và nhỏ. Chúng ta có thể sử dụng switch cisco SG500X-24 để kết nối các máy tính, máy in, camera hoăc các thiết bị wifi trong 1 phòng ban, trong các doanh nghiệp nhỏ với số lượng user ít... hoặc sử dụng để mở rộng mạng LAN trong các doanh nghiệp.
Thiết bị mạng switch cisco SG500X-24 tự động chuyển chế độ cáp thẳng hoặc chéo (MDI/MDI-X). Các tính năng Address Learning and Aging, and Data Flow Control giúp tối ưu truyền dữ liệu.Thiết kế để bàn.
High-Performance 10 Gigabit Ethernet
Easy Deployment and Use
High Reliability and Resiliency
High-Power Power over Ethernet Plus (PoE+)
Simplified IT Operation
True Stacking
Strong Security
Networkwide Automatic Voice Deployment
Expandability
IPv6 Support
Advanced Layer 3 Traffic Management
Power Efficiency
Peace of Mind and Investment Protection
Cisco Limited Lifetime Hardware Warranty
World-Class Service and Support
General Information | |
Product Name | SG500X-24 24-Port Gigabit + 4-Port 10-Gig Stackable Managed Switch |
Manufacturer Part Number | SG500X-24-K9-NA |
Product Series | 500 |
Product Model | SG500X-24 |
Packaged Quantity | 1 |
Product Type | Layer 3 Switch |
Interfaces/Ports | |
Total Number of Network Ports | 24 |
Uplink Port | No |
Modular | No |
Stack Port | Yes |
I/O Expansions | |
Number of Total Expansion Slots | 4 |
Number of SFP+ Slots | 4 |
Media & Performance | |
Media Type Supported | Twisted Pair |
Ethernet Technology | Gigabit Ethernet
Fast Ethernet |
Network Technology | 10/100/1000Base-T |
Network & Communication | |
Layer Supported | 3 |
Power Description | |
Power Source | Power Supply |
Management & Protocols | |
Manageable | Yes |
Physical Characteristics | |
Compatible Rack Unit | 1U |
Form Factor | Rack-mountable
Desktop |
Height | 1.7" |
Width | 17.3" |
Depth | 10.1" |
Warranty | |
Limited Warranty | Lifetime |
Other Information | |
Product Family | 500 |
PoE (RJ-45) Port | No |
Twisted Pair Cable Standard | Category 5 |
Token Ring Port | No |
LRE Port | No |
USB | No |
Number of Network (RJ-45) Ports | 24 |
Management Port | Yes |
Bypass | No |
Certifications & Standards |
|
Management |
|
Flash Memory | 32 MB |
Input Voltage | 110 V AC
220 V AC |
Standard Memory | 256 MB |
pported SFP/SFP+ modules |
SKU |
Media |
Speed |
Maximum Distance |
||||||||||
MFEFX1 | Multi-mode fiber | 100 Mbps | 2 km | |||||||||||
MFELX1 | Single-mode fiber | 100 Mbps | 15 km | |||||||||||
MFEBX1 | Single-mode fiber | 100 Mbps | 20 km | |||||||||||
MGBBX1 |
Single-mode fiber |
1000 Mbps |
10 km |
|||||||||||
MGBSX1 |
Multimode fiber |
1000 Mbps |
500 m |
|||||||||||
MGBLH1 |
Single-mode fiber |
1000 Mbps |
40 km |
|||||||||||
MGBLX1 |
Single-mode fiber |
1000 Mbps |
10 km |
|||||||||||
MGBT1 |
UTP cat 5e |
1000 Mbps |
100 m |
|||||||||||
SFP-H10GB-CU1M |
Copper coax |
10 Gig |
1 m |
|||||||||||
SFP-H10GB-CU3M |
Copper coax |
10 Gig |
3 m |
|||||||||||
SFP-H10GB-CU5M |
Copper coax |
10 Gig |
5 m |
|||||||||||
SFP-10G-SR |
Multimode fiber |
10 Gig |
26 m - 400 m |
|||||||||||
SFP-10G-LR |
Single-mode fiber |
10 Gig |
10 km |
|||||||||||
SFP-10G-SR-S |
Multimode fiber |
10 Gig |
26 m - 400 m |
|||||||||||
SFP-10G-LR-S |
Single-mode fiber |
10 Gig |
10 km |
Để có cấu hình, yêu cầu kỹ thuật chi tiết của Switch Cisco SG500X-24 cho vào hồ sơ tư vấn, thiết kế kỹ thuật hoặc cho vào hồ sơ mời thầu, quý khách vui long gửi email yêu cầu đến kd@cnttshop.vn
Bạn đang cần tư vấn về sản phẩm: #SG500X-24 ?
