| Datasheet Aruba 6200F 48G 4SFP+ Switch (JL726A) |
| Specifications |
| I/O ports |
- 48x ports 10/100/1000BASE-T ports
- 4x 1/10G SFP ports |
| Additional ports and slots |
- 1x USB-C console port
- 1x OOBM port
- 1x USB Type-A host port
- 1x Bluetooth dongle to be used with Aruba CX Mobile App |
| Power supplies |
Fixed power supply (200W) |
| Fans |
Fixed fans |
| Physical characteristics |
| Dimensions |
17.4(w) x 12.9(d) x 1.73(h) in 44.2 x 32.7 x 4.39 cm |
| Weight |
9.61 lbs (4.36 kg) |
| Hardware |
| CPU |
Quad Core ARM Cortex™ A72 @ 1.8 GHz |
| Memory |
8 GB DDR4 |
| Flash |
16 GB eMMC |
| Packet buffer |
8 MB packet buffer memory |
| Performance |
| Switching capacity |
176 Gbps |
| Throughput capacity |
Up to 130.9 Mpps |
| Average latency (LIFO-64-bytes packets) |
- 1 Gbps: 2.28 μSec
- 10 Gbps: 1.46 μSec |
| Stack size |
8 members |
| Max. stacking distance |
Up to 10 kms with long range transceivers |
| Environment |
| Operating temperature |
- 32°F to 113°F (0°C to 45°C) up to 5,000 ft
- Derate -1°C for every 1,000 ft from 5,000 to 10,000 ft |
| Operating relative humidity |
15% to 95% @ 104°F (40°C) non-condensing |
| Non-operating temperature |
-40°F to 158°F (-40°C to 70°C) up to 15,000 ft |
| Non-operating relative humidity |
15% to 90% @ 149°F (65°C) non-condensing |
| Max operating altitude |
Up to 10,000ft (3.048 Km) |
| Max non-operating altitude |
15,000 feet (4.6 km) max |
| Acoustics |
- Sound power, LWAd = 4.9 Bel
- Sound pressure, LpAm (bystander) = 33.0 dB |
| Primary airflow |
Front and side-to-back |
| Electrical characteristics |
| Frequency |
50Hz/60Hz |
| AC voltage |
100-120V/200-240V |
| Current |
2.5A/1.4A |
| 80plus.org certification |
80 PLUS Silver |
| Power consumption (230 VAC) |
- Hibernation (0 rpm fan): 7W
- Idle: 55W
- 100% traffic rate: 68W |
