| I/O ports and slots |
12x RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASET: full only
2x RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
2x SFP+ 1/10GbE ports; PHY-less
|
| Additional ports and slots |
1 dual-personality (RJ-45 or USB micro-B) serial console port.
|
| Physical characteristics |
Dimensions: 10 (w) x 10 (d) x 1.73 (h) in (25.4 x 25.4 x 4.39 cm) (1U height)
Weight: 4.85 lb (2.2kg)
|
| Memory and processor |
Dual Core ARM Cortex A9 @ 1016 MHz, 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB 4.5MB Ingress/7.785 Egress, 4 GB eMMC
|
| Performance |
1000 Mb Latency < 3.8 µs (64-byte packets)
10 Gb Latency < 1.6 µs (64-byte packets)
Throughut up to 41.7 Mpps
Switching capacity: 68 Gbps
Routing table size: 2,000 IPv4, 1,000 IPv6 in hardware, 200 OSPF, 256 Static, 10,000 RIP
MAC address table size: 32768 entries
|
| Environment |
Operating temperature: 32°F to 113°F (0°C to 45°C); up to 5000 Feet, - 0C to 40C (32F to 104F) up to 10000 Feet
Operating relative humidity: 15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage temperature:-40°F to 158°F (-40°C to 70°C); up to 15000 Feet.
Nonoperating/Storage relative humidity:15% to 95% @ 149°F (65°C), noncondensing
Acoustic: Power: 0 dB, Pressure: 0 dB Fanless
|
| Electrical characteristics |
Frequency: 50/60 Hz
Maximum heat dissipation: 68.2 BTU/hr (72.0 kJ/hr)
Voltage: 90 - 264 VAC, rated
Current: 1.7 A
Maximum power rating: 170 W
PoE power: 139 W PoE+
Notes: Maximum power rating and maximum heat dissipation are the worst-case theoretical : maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated
|
| Safety |
UL 60950-1, 2nd Edition; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; IEC 60950-1:2005 +A1:2009 +A2:2013; CSA 22.2 No. 60950-1-07 2nd; EN 60825-1:2007 / IEC 60825-1:2007 Class 1 |
| Emissions |
EN 55022:2010/CISPR 22 Class A; FCC CFR 47 Part 15 Class A; VCCI Class A; ICES-003 Class A; CNS 13438
|
| Management |
Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface; Web browser; Configuration menu; SNMP manager; Telnet; RMON1; FTP; Out-of-band management (serial RS-232C or micro USB) |
Switch
.png){kind=icon}
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: JL693A ?
Báo giá thiết bị chuyển mạch JL693A Aruba 2930F 12G PoE+ 2G/2SFP+ đã được gửi qua mail, bạn check ibox nhé.
Chào anh/chị, switch Aruba JL693A có một số tính năng layer 3 như: static route, Access OSPF, DHCP server, policy-base routing nên nếu hệ thống nhỏ và không yêu cầu năng lực xử lý quá cao thì cũng có thể sử dụng làm core switch ạ.
Thiết bị chuyển mạch JL693A có hỗ trợ PoE với tổng công suất lên tới 139W bạn nhé
Báo giá Aruba 2930F series Switch JL693A 12 RJ-45 PoE+ autosensing 10/100/1000 ports, 2 SFP/SFP+ 1G/10G ports đã được gửi vào mail, bạn vui lòng check mail nhé.
Thiết bị chuyển mạch Switch Aruba JL693A không hỗ trợ stack nguồn nhé bạn.
