Aruba 9240 (RW) Campus Gateway R7J03A
| Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Thông số kỹ thuật Aruba R7J03A
| Datasheet R7J03A | |
| Specification | |
| Form Factor | Rack 1U |
| Interface | 4x SFP28 |
| Out of Band Management Port | 1 port RJ45 |
| Console port | 1 port USB-C 1 port RJ45 |
| USB 3.0 Type-A | 2 port |
| LCD Display | 1 |
| Power LED | Yes |
| Status LED | Yes |
| Peered LED (Reserved for Future Use) | Yes |
| Expansion Slot (Reserved for Future Use) | 1 Slots |
| Power Supply Slots | 1 + Redundant |
| Fan Trays | 5 |
| Physical | |
| Dimensions (HxWxD) | 1.73" x 17.40" x15.60" 4.4 cm x 44.2cm x 39.6 cm |
| Weigh | 18.08 lbs 8.2 kg |
| MTBF (Hours at 25C with Fans and PSU) | 185,301 |
| Environmentals | |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Humidity/Storage Humidity | 10% to 90% (RH)/10% to 95% (RH), non-condensing |
| Operating Altitude | 10,000 feet |
| Acoustic Noise | 65.2 dBA (Typ) |
| Maximum Heat Dissipation (BTU/hour) | 648 BTU/hr |
| Maximum Power Consumption | 190W |
| Power Source | 550-watt power supply |
| Power Supply Certifications | |
| Input voltage range | 100 VAC to 240 VAC |
| Output Voltage | 12V |
| Input frequency | 50-60 Hz |
| AC line input current (steady state) | 7.1A |
| Operating Temperature | 0° C to 55° C |
| Cooling | nternal fan (Air flow rear to front) |
Bạn đang cần tư vấn về sản phẩm: R7J03A ?
