| Datasheet JL817A |
| Specifications |
| Description |
4x ports 100M/1G BaseT Class 6 PoE ports supporting up to 60W per port 8x ports 100M/1G BaseT Class 4 PoE ports supporting up to 30W per port
2x 1/10G SFP ports
Supports PoE Standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W)
1x USB-C Console Port
1x RJ Console
1x USB Type A Host port
1x Alarm socket
2x DC power socket
|
| Power Supplies |
Field replaceable Industrial DIN Rail Power Supplies
Supported PSUs: JL819A, JL820A and JL821A
Supported 2 PSU with redundancy, non sharing
See external PSU specification table for available PoE power
|
| Fans |
Fanless |
| Physical Characteristics |
| Dimensions |
(H) 160 mm x (W) 113 mm x (D) 162.9 mm (173.5 mm w/DIN Rail Bracket)[6.3” x 4.4” x 6.4”(6.8” w/DIN Rail Bracket)] |
| Weight |
3.84 kg (8.46 lbs) |
| Mounting And Enclosure |
Cable management kit included. 2‑post rack mounting kit included. 4‑post rack mounting kit available separately |
| Additional Specifications |
| CPU |
Dual Core ARM Cortex A9 @ 1016 Mhz |
| Memory And Flash |
4 GB DDR3 32 GB eMMC |
| Packet Buffer |
12.38MB (4.5MB Ingress/7.875MB Egress) |
| Performance |
| Model Switching Capacity |
up to 64 Gbps |
| Model Throughput Capacity |
up to 46 Mpps |
| Average Latency (LIFO-64-bytes packets) |
1 Gbps: 2.390μSec , 10 Gbps: 2.038μSec |
| Switched Virtual Interfaces (dual stack) |
1G: 5.32 μSec
10G: 1.48 μSec
25G: 2.78 μSec
40G: 1.31 μSec
100G: 1.42 μSec
|
| IPv4 host table (ARP) |
756 |
| IPv6 host table (ND) |
576 |
| IPv4 unicast routes |
576 |
| IPv6 unicast routes |
576 |
| MAC Table Size |
8192 |
| IGMP Groups |
512 |
| MLD groups |
512 |
| IPv4/IPv6/MAC ACL entries (ingress) |
256 / 128 / 256 |
| Environment |
| Operating temperature |
-40°C to 60°C, 0m/s (-40°F to 140°F, 0 LFM)
-40°C to 70°C, 0.2m/s (-40°F to 158°F, 40 LFM)
-34°C to 75°C, 1m/s (-29.2°F to 167°F, 200 LFM)
|
| Non-Operating Storage relative humidity |
5% to 95%, non-condensing |
| Max Operating Altitude |
up to 4.2 km (13800 ft) Max |
| Max non-operating Altitude |
4.6 km (15000 ft) Max |
| Safety |
Europe: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 EN 62368-1, Ed.2:2014 North America: UL 62368-1, 2nd Edition CAN/CSA C22.2 No. 62368-1-14 Worldwide: IEC 60950-1:2005 Ed.2 + Am 1:2009 + A2:2013 IEC 62368-1:2014 EN/IEC 60825-1:2014 Class 1 UL/IEC 61010-2-201 GB 4943.1:2011 CNS 14336-1 K 60950-1 |
