| Datasheet Aruba JL667A |
| Specifications |
| I/O ports and slots |
|
| Additional |
|
| Ports And Slots |
1x OOBM
1x USB Type A host port
1x Bluetooth dongle to be used with CX Mobile App
|
| Power supplies |
Internal (fixed) power supply (160W)
|
| Fan tray |
Fixed fans.
|
| Physical characteristics |
| Dimensions |
17.4 (w) x 12.9 (d) x 1.73 (h) in
(44.2 cm x 32.7 x 4.39 cm))
|
| Weight |
9.83 lbs (4.46 kg) |
| CPU, Memory And Flash |
| Processor |
Quad Core ARM Cortex™ A72 @ 1.8GHz |
| Memory |
8 GBytes DDR4
|
| Flash |
32 GBytes eMMC |
| Mounting and enclosure |
Rack Mount 1U |
| Performance |
| Packet Buffer |
8 MB packet buffer memory
|
| System switching capacity |
880 Gbps |
| System throughput capacity |
660 Mpps |
| Model switching capacity |
496 Gbps |
| Model throughput capacity |
369 Mpps |
|
Average latency
(LIFO, 64-byte packets)
|
-
1Gbps: 2.28µSec
-
10Gbps: 1.46µSec
-
25Gbps: 1.90µSec
-
50Gbps: 3.49µSec
|
| Stack size |
10 members |
| Max stacking distance |
Up to 10 kms with long range transceivers |
| Stacking bandwidth |
200 Gbps |
| Switched virtual interfaces (dual stack) |
1,000 |
| IPv4 host table (ARP) |
28,800 |
| IPv6 host table (ND) |
28,800 |
| IPv4 unicast routes |
64,000 |
| IPv6 unicast routes |
32,000 |
| IPv4 multicast routes |
8,000 |
| IPv6 multicast routes |
8,000 |
| MAC table capacity |
29,490 |
| IGMP groups |
8,000 |
| MLD groups |
4,000 |
| IPv4/IPv6/MAC ACL entries (ingress) |
5000/1250/5000 |
| IPv4/IPv6/MAC ACL entries (engress) |
2000/500/2000 |
| Environment |
| Operating temperature |
32°F to 113°F (0°C to 45°C), up to 5,000 feet
32°F to 104°F (0°C to 40°C), 5,001 to 10,000 feet
1°C de-rating per 1,000 feet above 5,000 feet
Can support excursion to 131°F (55°C) for short periods of time.
|
| Operating relative humidity |
15% to 95% relative humidity at 104°F (40°C), non-condensing |
| Non-operating temperature |
-40°F to 158°F ('-40°C to 70°C) |
| Non-operating humidity |
15% to 95% relative humidity at 149°F(65°C), non-condensing |
| Max operating altitude |
Up to 10,000ft (3.048 Km) |
| Max non-operating altitude |
Up to 15,000ft (3.048 Km) |
| Acoustic |
Sound power, LWAd = 4.9 Bel
Sound pressure, LpAm (bystander) = 31.5 dB
|
| Primary airflow |
Front and side-to-back |
| Electrical characteristics |
| Frequency |
50/60 Hz
|
| AC voltage |
Fixed PSU: 100V-120V/200V-240V |
|
Current (for voltages listed above)
|
Fixed PSU: 2.5A/1.4A |
| Power consumption (230VAC) |
Hibernation (0 rpm fan): 6W
Idle: 52W
100% traffic rate: 74W
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: JL667A ?
Nhân viên kinh doanh sẽ liên hệ báo giá qua mail. Để hỗ trợ nhanh nhất bạn liên hệ 0862323559 (Ms Hằng)
Switch Aruba JL667A 6300F 48 Ports do bên Cnttshop cung cấp, đươc bảo hành 12 tháng ah.
Thiết bị chuyển mạch JL667A hỗ trợ các cổng như sau:
48x ports 10/100/1000 BASE-T
4x 1/10/25/50G SFP ports
Thiết bị chuyển mạch Aruba JL667A 6300F 48 Ports 10/100/1000 Hoạt động ở layer 3 bạn nhé.
