Features
|
Technical Specification
|
Processor
|
Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 24 cores per processor
|
Memory
|
16 DDR4 DIMM slots, Supports RDIMM / LRDIMM, speeds up to 2666MT/s, 1TB max
|
Storage controllers
|
- Internal Boot: PERC H330, H730P, H740P, HBA330
- External Controllers: H840, 12 Gbps SAS HBA
- Software RAID: S140
- Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SSDs 240GB, 480GB
- Internal Dual SD Module
|
Drive bays
|
- Front drive bays: Up to 10 x 2.5” SAS/SATA (HDD/SSD) with up to 4 NVMe SSD max 76.8TB or up to 4 x 3.5 SAS/SATA HDD max 64TB
- Optional: DVD-ROM, DVD+RW
|
Power supplies
|
- Bronze: 450W (Cabled PSU)
- Platinum: 550W (Hot plug PSU with full redundancy option)
|
Fans
|
Up to six cabled fans
|
Sizing
|
- Form factor: Rack (1U)
- Height: 42.8mm (1.68”)
- Width: 434mm (17.08”)
- Depth: 714.62mm (28.13”)
- Weight: 17.6kg (38.9lbs.)
Dimensions do not include bezel
|
Bezel
|
Optional LCD or security bezel
|
Embedded / At-Server
|
- iDRAC9
- iDRAC Direct
- iDRAC REST API with Redfish
- Quick Sync 2 BLE/wireless module
|
Consoles & Mobile
|
- OpenManage Enterprise
- OpenManage Essentials
- OpenManage Mobile
- OpenManage Power Center
|
Integrations
|
- OpenManage integrations: Microsoft® System Center, VMware® vCenter™, BMC Truesight, Red Hat® Ansible® Modules
- OpenManage connections: Nagios® & Nagios® XI, IBM Tivoli Netcool/OMNIbus, Micro Focus Operations Manager I
|
Tools
|
- Dell EMC Repository Manager
- Dell EMC Update Package
- Dell EMC System Update
- Dell EMC Server Update Utility
- iDRAC Service Module
- OpenManage Server Administrator
- OpenManage Storage Services
|
Security
|
- TPM 1.2/2.0, TCM 2.0 optional
- Cryptographically signed firmware
- Silicon Root of Trust
- Secure Boot
- System Lockdown (requires OpenManage Enterprise)
- System Erase
|
I/O & Ports
|
- Network options: 2 x 1GbE LOM + (optional) LOM Riser 2 x 1GbE or 2x 10GbE SFP+ or 2 x 10GbE BaseT
- Front ports: 1 x Dedicated iDRAC Direct USB, 1 x USB 2.0, 1 x Video
- Rear ports: 1 x Dedicated iDRAC network port, 1 x Serial, 2 x USB 3.0, 1 x Video
- Up to 2 x PCIe Gen 3 slots all x16
|
Supported operating systems
|
- Canonical® Ubuntu® Server LTS
- Citrix® Hypervisor
- Microsoft Windows Server® LTSC with Hyper-V
- Red Hat® Enterprise Linux
- SUSE® Linux Enterprise Server
- VMware® ESXi
|
OEM-ready version available
|
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
|
Recommended support and services
|
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information.
|
