Juniper QFX5200-48Y-AFO QFX5200-48Y 48 SFP+/SFP28 ports, front-to-back airflow

Name: QFX5200-48Y-AFO
Brand: Juniper
SKU: QFX5200-48Y-AFO
Availability: InStock
Rating: 5 (45 reviews)

Juniper Part Number : QFX5200-48Y-AFO
Bảo hành : 12 tháng
List Price : $25,000
Made In : China
Stock : Liên hệ

Mô tả tổng quan

Các nhà khai thác mạng đang ngày càng triển khai các kiến trúc spine-and-leaf IP fabric, được xây dựng với các Switch có cấu hình cố định để hỗ trợ lưu lượng truy cập ngày càng tăng trong trung tâm dữ liệu. Dòng thiết bị chuyển mạch Juniper QFX5200-48Y-AFO cung cấp các cổng 10G/25G SFP+/SFP28 và các cổng uplink 40GbE và 100GbE linh hoạt, tiết kiệm chi phí, bảo vệ đầu tư và tương lai cho các trung tâm dữ liệu ngày nay.

View Datasheet QFX5200-48Y-AFO

Ngoài việc triển khai lớp core trong kiến trúc IP fabric, các bộ chuyển mạch Juniper QFX5200-48Y-AFO cũng rất phù hợp cho việc triển khai mạng multitier, multichassis link aggregation (MC-LAG) thường được sử dụng trong các mạng doanh nghiệp.

Juniper QFX5200-48Y-AFO QFX5200-48Y 48 SFP+/SFP28 ports, front-to-back airflow

Thông số kỹ thuật Switch Juniper QFX5200-48Y-AFO

Hardware
System throughput	3.6 Tbps (bi-directional)
Forwarding capacity	2.1 Bpps
QSFP+/QSFP28 ports	6 QSFP+ or QSFP28
SFP+/SFP28	48 SFP+ or SFP28
Maximum 10GbE port density	48
Maximum 25GbE port density	48
Maximum 40GbE port density	6
Maximum 50GbE port density	-
Maximum 100GbE port density	6
Dimensions (W x H x D)	17.36 x 1.70 x 20.28 in. (44.09 x 4.31 x 51.5 cm)
Rack units	1 U
Weight	21.2 lb (9.6 kg)
Operating system	Junos OS
CPU	Intel Quad Core Broadwell-DE 2.3 GHz CPU, 16 GB SDRAM, 32 GB SSD
Management and Precision Time Protocol (PTP) interfaces	• 1 RJ-45 10/100/1000 BASE-T for management • 1 RS-232 console port • 1 USB 2.0 port
Power	• Redundant (1+1) hot-pluggable 650 W AC power supplies
Cooling	• front-to-back cooling • Redundant (N+1) hot-pluggable fan modules
Total packet buffer	22 MB
Environmental Ranges
Operating temperature	32° to 95° F (0° to 35° C)
Storage temperature	-40° to 158° F (-40° to 70° C)
Operating altitude	Up to 10,000 ft. (3,048 m)
Relative humidity operating	5 to 90% (noncondensing)
Relative humidity nonoperating	5 to 95% (noncondensing)
Seismic	Designed to meet GR-63, Zone 4 earthquake requirements
Maximum Thermal Output
Maximum power draw	430 W (AC, DC), 1467 BTU/hr
Typical power draw	382 W (AC, DC), 1303 BTU/hr
Safety and Compliance
Safety	• CAN/CSA-C22.2 No. 60950-1 Information Technology Equipment—Safety • UL 60950-1 Information Technology Equipment—Safety • EN 60950-1 Information Technology Equipment—Safety • IEC 60950-1 Information Technology Equipment—Safety (All country deviations) • EN 60825-1 Safety of Laser Products—Part 1: Equipment Classification
Electromagnetic Compatibility	• 47 CFR Part 15, (FCC) Class A • ICES-003 Class A • EN 55022/EN 55032, Class A • CISPR 22/CISPR 32, Class A • EN 55024 • CISPR 24 • EN 300 386 • VCCI Class A • AS/NZS CISPR 32, Class A • KN32/KN35 • BSMI CNS 13438, Class A • EN 61000-3-2 • EN 61000-3-3 • ETSI • ETSI EN 300 019: Environmental Conditions & Environmental Tests for Telecommunications Equipment • ETSI EN 300 019-2-1 (2000)—Storage • ETSI EN 300 019-2-2 (1999)—Transportation • ETSI EN 300 019-2-3 (2003)—Stationary Use at Weatherprotected Locations • ETSI EN 300 019-2-4 (2003)—Stationary Use at NonWeather-protected Locations • ETS 300753 (1997)—Acoustic noise emitted by telecommunications equipment
Environmental Compliance	Restriction of Hazardous Substances (ROHS) 6/6 China Restriction of Hazardous Substances (ROHS) Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) Waste Electronics and Electrical Equipment (WEEE) Recycled material 80 Plus Silver PSU Efficiency
Telco	Common Language Equipment Identifier (CLEI) code

Power Supply và Fans có thể sử dụng cho Switch Juniper QFX5200-48Y-AFO

QFX520048Y-APSU-AO	Juniper 650 W AC power supply for QFX5200-48Y (power supply-side airflow intake)
QFX520048Y-FAN-AO	QFX5200-32C fan module, front-to-back airflow
EX-4PST-RMK	4 post rack mount
QFX520048Y-RKMT	4 post rack-mount for QFX5200-48Y

License Software sử dụng cho Switch Juniper QFX5200-48Y-AFO

QFX5K-C1-PFL	QFX5000 Class 1 Premium Feature License for QFX5200-48Y
QFX5K-C1-AFL	QFX5000 Class 1 Advanced Feature License for QFX5200-48Y

Module quang Juniper có thể sử dụng cho Switch Juniper QFX5200-48Y-AFO

QFX-SFP-10GE-USR	SFP+ 10GbE Ultra Short Reach optics, 850 nm for 10 m on OM1, 20 m on OM2, 100 m on OM3 multimode fiber (for management port)
QFX-SFP-10GE-SR	SFP+ 10GBASE-SR 10GbE optics, 850 nm for up to 300 m transmission on multimode fiber-optic (MMF) (for management port)
QFX-SFP-10GE-LR	SFP+ 10GBASE-LR 10GbE optics, 1310 nm for 10 km transmission on single-mode fiber-optic (SMF) (for management port)
QFX-SFP-DAC-1M	SFP+10 GbE direct attach copper (DAC) (twinax copper cable) 1 m for QFX5200-48Y
QFX-SFP-DAC-3M	SFP+10 GbE DAC (twinax copper cable) 3 m for QFX5200-48Y
QFX-SFP-DAC-5M	SFP+10 GbE DAC (twinax copper cable) 5 m for QFX5200-48Y
JNP-SFP-25G-SR	25GBASE-SR SFP28 module for MMF for QFX5200- 48Y
JNP-SFP-25G-DAC-1M	SFP 25GBASE DAC cable 1 m for QFX5200-48Y
JNP-SFP-25G-DAC-3M	SFP 25GBASE DAC cable 3 m for QFX5200-48Y
JNP-SFP-25G-DAC-5M	SFP 25GBASE DAC cable 5 m for QFX5200-48Y
QFX-QSFP-DAC-1M	QSFP+ to QSFP+ Ethernet Direct Attach Copper (twinax copper cable) 1m passive
QFX-QSFP-DAC-3M	QSFP+ to QSFP+ Ethernet Direct Attach Copper (twinax copper cable) 3m passive
JNP-QSFP-4X10GE-IR	QSFP+ 40GBASE optics, up to 1.4 km transmission on parallel single mode (4X10GbE long reach up to 1.4 km)
JNP-QSFP-4X10GE-LR	QSFP+ 40GBASE optics, up to 10 km transmission on parallel single mode (4X10GbE long reach up to 10 km)
JNP-QSFP-40GE-IR4	QSFP+ 40GBASE-IR4 40-gigabit optics, 1310 nm for up to 2 km transmission on SMF
JNP-QSFP-DAC-10MA	QSFP+ to QSFP+ Ethernet DAC (twinax copper cable) 10 m active
JNP-QSFP-DAC-7MA	QSFP+ to QSFP+ Ethernet DAC (twinax copper cable) 7 m active
JNP-QSFP-DAC-5M	QSFP+ to QSFP+ Ethernet DAC (twinax copper cable) 5 m passive
QFX-QSFP-DACBO-1M	QSFP+ to SFP+ 10 Gigabit Ethernet Direct Attach Breakout Copper (twinax copper cable) 1m
QFX-QSFP-DACBO-3M	QSFP+ to SFP+ 10 Gigabit Ethernet Direct Attach Breakout Copper (twinax copper cable) 3m
JNP-QSFP-DACBO-5MA	QSFP+ to SFP+ 10GbE direct attach breakout copper (twinax copper cable) 5 m active
JNP-QSFP-DACBO-7MA	QSFP+ to SFP+ 10GbE direct attach breakout copper (twinax copper cable) 7 m active
JNP-QSFP-DACBO-10M	QSFP+ to SFP+ 10GbE direct attach breakout copper (twinax copper cable) 10 m active
EX-QSFP-40GE-DAC-50CM	40GbE QSFP+ 0.5 m direct-attach
JNP-40G-AOC-20M	40GbE active optical cable for 20 m
JNP-40G-AOC-30M	40GbE active optical cable for 30 m
QFX-QSFP-40G-SR4	QSFP+ 40GBASE-SR4 40 Gigabit Optics, 850 nm for up to 150 m transmission on MMF
QFX-QSFP-40G-ESR4	QSFP+ 40GBASE-ESR4 40 Gigabit Optics, 300 m(400 m) with OM3(OM4) MMF
JNP-QSFP-40G-LR4	QSFP+ 40GBASE-LR4 40 Gigabit Optics, 1310nm for up to 10km Transmission on SMF
JNP-QSFP-40G-LX4	QSFP+ 40GBASE-LX4 40 Gigabit Optics, 100m(150m) with OM3(OM4) duplex MMF
JNP-QSFP-100G-SR4	QSFP28 100GbE, SR4, 100 m
JNP-QSFP-100G-PSM4	QSFP28 100GBASE-PSM4 optics for up to 500 m transmission over parallel SMF
JNP-100G-DAC-1M	QSFP28 to QSFP28 Ethernet Direct Attach Copper (twinax copper cable), 1 m
JNP-100G-DAC-3M	QSFP28 to QSFP28 Ethernet Direct Attach Copper (twinax copper cable), 3 m
JNP-100G-AOC-1M	100GbE active optical cable for 1 m
JNP-100G-AOC-15M	100GbE active optical cable for 15 m
JNP-100G-AOC-20M	100GbE active optical cable for 20 m
JNP-QSFP-100G-CWDM	QSFP28 100GbE, CWDM4, 2 km
JNP-QSFP-100G-LR4	QSFP28 100GbE, LR4, 10 km

Để có cấu hình, yêu cầu kỹ thuật chi tiết của Switch Juniper QFX5200-48Y-AFO cho vào hồ sơ tư vấn, thiết kế kỹ thuật hoặc cho vào hồ sơ mời thầu, quý khách vui lòng gửi email yêu cầu đến kd@cnttshop.vn
