Hardware specifications
|
|
Flash Memory
|
128 MB
|
|
DRAM
|
512 MB
|
|
CPU
|
APM86392 600 MHz dual core
|
|
Console ports
|
USB (Type B), Ethernet (RJ-45)
|
|
Storage interface
|
USB (Type A) for external flash storage
|
|
Network management interface
|
10/100 Mbps Ethernet (RJ-45)
|
|
Interface
|
48 10/100/1000 PoE+ Ethernet ports
|
|
Uplink interfaces
|
4 x 1Gb SFP
|
|
Performance and scalability
|
|
Forwarding bandwidth
|
108 Gbps
|
|
Switching bandwidth
|
216 Gbps
|
|
Maximum active VLANs
|
1023
|
|
VLAN IDs available
|
4096
|
|
Maximum Transmission Unit (MTU)-L3 packet
|
9198 bytes
|
|
Jumbo frame - Ethernet frame
|
9216 bytes
|
|
Forwarding rate: 64-byte Layer 3 packets
|
107.1 Mpps
|
|
Resource
|
|
Unicast MAC
|
16,000
|
|
ARP Entries
|
8000
|
|
IPv4 unicast direct routes
|
2000
|
|
IPv4 unicast indirect routes
|
1000
|
|
IPv6 unicast direct routes
|
2000
|
|
IPv6 unicast indirect routes
|
1000
|
|
IPv4 multicast routes and IGMP groups
|
1000
|
|
IPv6 multicast groups
|
1000
|
|
IPv4 QoS ACEs
|
500
|
|
IPv6 QoS ACEs
|
500
|
|
IPv4 security ACEs
|
600
|
|
IPv6 Security ACEs
|
600
|
| Voltage and power ratings |
|
Predicted reliability (MTBF in hours**)
|
232,610
|
|
Power rating
|
0.89 kVA
|
|
DC input voltages
|
12V - 4A / 53V - 15A
|
|
Input voltage and current
|
100 to 240 VAC/9A to 4A/50 to 60 Hz
|
|
Available PoE power
|
740W
|
|
Maximum number of PoE+
|
24 ports up to 30W
48 ports up to 15.4W
|
|
Dimensions
|
|
Inches (H x D x W)
|
1.75 x 14.5 x 17.5
|
|
Centimeters (H x D x W)
|
4.5 x 36.8 x 44.5
|
|
Pounds
|
12.9
|
|
Kilograms
|
5.8
|
|
Environmental ranges
|
|
Operating temperature up to 10,000 ft (3000 m)
|
23º to 113ºF / -5º to 45ºC
|
|
Operating altitude (Feet/Meters)
|
Up to 10,000/Up to 3000
|
|
Operating relative humidity
|
10% to 95% noncondensing
|
|
Safety and compliance (Safety)
|
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: WS-C2960X-48FPS-L ?
Chào anh,
Cisco WS-C2960X-48FPD-L hỗ trợ các cổng Uplink 10GE trong khi WS-C2960X-48FPS-L chỉ hỗ trợ các cổng Uplink 1GE.
Thong tin đến anh!
Để sử dụng được stack Switch Cisco WS-C2960X-48FPS-L phải mua module stack C2960X-STACK và cap stack anh nhé. Báo giá đã được gửi vào mail vui lòng check mail để biết được thông tin.
CNTTShop đã gửi báo giá thiết bị Cisco WS-C2960X-48FPS-L qua email, anh check inbox nhé.
Chào anh/chị.
Switch cisco WS-C2960X-48FPS-L với tổng công suất 740W có thể cấp nguồn cho tối đa 48 thiết bị wifi cisco AIR-AP1832I-S-K9
Switch cisco WS-C2960X-48FPS-L có thể cấp nguồn đủ cho 24 thiết bị wifi cissco AIR-AP1832I-S-K9 nhé bạn.
