WS-C2960XR-48FPS-I Cisco Catalyst 2960XR Stackable 48 PoE+ 740W, 4 SFP, IP Lite
Switch Cisco WS-C2960XR-48FPS-I Catalyst 2960XR Stackable 48 Ports 10/100/1000 PoE+ 740W Layer 3 Basic, 4 x 1G SFP Slot Uplink, IP Lite
- Danh mục sản phẩm Switch Cisco 2960X Series
- Scenario
- Switch Type
- Số Cổng
- Routing/Switching
- Downlink Ports
- Uplink Ports
- Management
- Configurations
- Features
Switch Cisco WS-C2960XR-48FPS-I
| Cisco Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Switch Cisco 2960X WS-C2960XR-48FPS-I là thiết bị chuyển mạch lớp access, cung cấp các kết nối đến các thiết bị đầu cuối trong hệ thống mạng.
Switch Cisco WS-C2960XR-48FPS-I cung cấp 48 cổng Giga 10/100/1000 Mps Base-T PoE với 04 Uplink GE SFP để kết nối đường quang Multimode hoặc Single Mode. WS-C2960XR-48FPS-I sử dụng nguồn dạng module có thể thay thế.
Thông số kỹ thuật chi tiết của WS-C2960XR-48FPS-I
|
Hardware specifications |
|
|
Flash Memory |
128 MB |
|
DRAM |
512 MB |
|
CPU |
APM86392 600 MHz dual core |
|
Console ports |
USB (Type B), Ethernet (RJ-45) |
|
Storage interface |
USB (Type A) for external flash storage |
|
Network management interface |
10/100 Mbps Ethernet (RJ-45) |
|
Interface |
48 10/100/1000 Ethernet ports |
|
Uplink interfaces |
4 x 1Gb SFP |
|
Performance and scalability |
|
|
Forwarding bandwidth |
108 Gbps |
|
Switching bandwidth |
216 Gbps |
|
Maximum active VLANs |
1023 |
|
VLAN IDs available |
4096 |
|
Maximum Transmission Unit (MTU)-L3 packet |
9198 bytes |
|
Jumbo frame - Ethernet frame |
9216 bytes |
|
Forwarding rate: 64-byte Layer 3 packets |
107.1 Mpps |
|
Scalability (Default/VLAN/IPv4) |
|
|
Unicast MAC |
16,000 / 32,000 / 16,000 |
|
IPv4 unicast direct routes |
4000 / 250 / 16,000 |
|
IPv4 unicast indirect routes |
1250 / 250 / 8000 |
|
IPv6 unicast direct routes |
4000 / 250 / 0 |
|
IPv6 unicast indirect routes |
1250 / 250 / 0 |
|
IPv4 multicast routes and IGMP groups |
1000 / 1000 / 1000 |
|
IPv6 multicast groups |
1000 / 1000 / 0 |
|
IPv4 QoS ACEs |
500 / 500 / 500 |
|
IPv6 QoS ACEs |
250 / 500 / 0 |
|
IPv4 security ACEs |
1000 / 1000 / 875 |
|
IPv6 Security ACEs |
500 / 500 / 0 |
|
IPv4 policy-based routing ACEs |
500 / 0 / 375 |
| Voltage and power ratings | |
|
Predicted reliability (MTBF in hours**) |
230,860 |
|
Power rating |
0.89KVA |
|
Input voltage and current |
100 to 264 VAC / 10A to 5A / 50 to 60 Hz |
|
Power Capacity |
24 ports up to 30W, 48 ports up to 15.4W |
|
Available PoE power |
740W |
|
Dimensions |
|
|
Inches (H x D x W) |
1.75 x 16.0x 17.5 |
|
Centimeters (H x D x W) |
4.45 x 40.8 x 44.5 |
|
Pounds |
14.7 |
|
Kilograms |
6.7 |
|
Environmental ranges |
|
|
Operating temperature up to 10,000 ft (3000 m) |
23º to 113ºF / -5º to 45ºC |
|
Operating altitude (Feet/Meters) |
Up to 10,000/Up to 3000 |
|
Operating relative humidity |
10% to 95% noncondensing |
|
Safety and compliance (Safety) |
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 |
