Switch Cisco WS-C3650-24PS-L

Hardware Specifications

10/100/1000 Ethernet Ports

24 PoE+

Fixed Uplinks

4 x Gigabit Ethernet with Small Form‑Factor Pluggable (SFP)

Default AC Power Supply

640 WAC

Available PoE Power

390 W

Performance Specifications

Switching capacity

92 Gbps

Stacking bandwidth

160 Gbps

Total number of MAC addresses

32,000

Total number of IPv4 routes (ARP plus learned routes)

24,000

FNF entries

24,000 flows

DRAM

4 GB

Flash

2 GB

VLAN IDs

4,094

Total switched virtual interfaces (SVIs)

1,000

Jumbo frame

9198 bytes

Total routed ports per 3650 stack

208

Wireless

Number of access points per switch/stack

25

Number of wireless clients per switch/stack

1000

Total number of WLANs per switch

64

Wireless bandwidth per switch

Up to 20 Gbps

Supported Aironet access point series

3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040

Forwarding Rate

41.66 Mpps

Dimensions

Dimensions (H x W x D) (Inches/Centimeters)

1.73 x 17.5 x 17.625/4.4 x 44.5 x 44.8

Weight (Pounds/Kilograms)

16/7.26

MTBF Hours

528,280

Environmental Ranges

With AC Power Supply

Operating Environment and Altitude

-5ºC to +45ºC, up to 5000 feet (1500m)

-5ºC to +40ºC, up to 10,000 feet (3000m)

-5ºC to +35ºC, up to 13,000 feet (4000m)

-5ºC to +30ºC, up to 16,400 feet (5000m)

With DC Power Supply

Operating Environment and Altitude (NEBS)

-5ºC to +45ºC, up to 5000 feet (1500m)

-5ºC to +45ºC, up to 10,000 feet (3000m)

Safety and Compliance

Safety Certifications

UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition
EN 60950-1 Second Edition
IEC 60950-1 Second Edition
GOST
NOM (obtained by partners and distributors)

Electromagnetic Emissions Certifications

47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class
KCC
CNS13438 Class A
EN55024
CISPR24
KN24
