Description
|
Specifications
|
| Performance |
|
Switching capacity
|
352 Gbps
|
|
Forwarding rate
|
261.90 Mpps
|
| Switch capacity with Stacking |
532 Gbps |
| Forwarding rate with Stacking |
395 Mpps |
|
Virtual Networks
|
4
|
|
Stacking bandwidth
|
160 Gbps
|
|
DRAM
|
4 GB
|
|
Flash
|
4 GB
|
|
Features
|
| Switch fundamentals |
Layer 2, Routed Access (RIP, EIGRP Stub, OSPF - 1000 routes), PBR, PIM Stub Multicast (1000 routes), PVLAN, VRRP, PBR, CDP, QoS, FHS, 802.1X, MACsec-128, CoPP, SXP, IP SLA Responder |
| Advanced switch capabilities and scale |
EIGRP, HSRP, IS-IS, BSR, MSDP, IP SLA, OSPF |
| Network segmentation |
VRF, VXLAN, LISP, SGT |
| Advanced switch capabilities and scale |
EIGRP, HSRP, IS-IS, BSR, MSDP, IP SLA, OSPF
|
|
Telemetry and visibility
|
Model-driven telemetry, sampled NetFlow, SPAN, RSPAN
|
|
Security
|
MACsec-128
|
|
Physical Specifications
|
| Chassis Dimensions |
1.73 x 17.5 x 13.8 Inches
4.4 x 44.5 x 35.0 Centimeters |
| weight |
11.33 Pounds
5.1 Kilograms |
| Mean time between failures (hours) |
353,960 |
| Connectors |
| Standards, Safety and compliance information |
| Standards |
EEE 802.1s
IEEE 802.1w
IEEE 802.1x
IEEE 802.1x-Rev
IEEE 802.3ad
IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1p CoS prioritization
IEEE 802.1Q VLAN
IEEE 802.3 10BASE-T specification
IEEE 802.3u 100BASE-TX specification
IEEE 802.3ab 1000BASE-T specification
IEEE 802.3z 1000BASE-X specification
IEEE 802.3bz 10G BASE-T specification
RMON I and II standards
SNMPv1, v2c, and v3
|
| Safety certifications |
- IEC 60950-1
- UL 60950-1
- CAN/CSA C22.2 No. 60950-1
- EN 60950-1
- AS/NZS 60950.1
- Class I Equipment
|
| Electromagnetic emissions certifications |
- 47 CFR Part 15
- CISPR 22 Class A
- CISPR 32 Class A
- CNS 13438
- EN 300 386
- EN 55022 Class A
- EN 55032 Class A
- EN61000-3-2
- EN61000-3-3
- ICES-003 Class A
- KN 32
- TCVN 7189 Class A
- V-3 Class A
- CISPR 24
- EN 300 386
- EN 55024
- KN 35
- TCVN 7317
|
| Environmental |
Reduction of Hazardous Substances (ROHS) 5
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
Bạn đang cần tư vấn về sản phẩm: C9200-24PXG-A ?
Chào bạn,
Sản phẩm Switch Cisco C9200-48PXG-A cung cấp 48 Cổng Gigabit trong khi sản phẩm C9200-24PXG-A cung cấp 24 cổng Gigabit.
Thông tin đến bạn!
Phụ kiện đi kèm Thiết bị chuyển mạch Cisco C9200-24PXG-A gồm: dây nguồn C13, tai bắt rack anh nhé.
Chào anh/chị, khi mua switch Cisco 9200 series bắt buộc phải có license DNA -A hoăc -E ạ.
Được nhé bạn, Báo giá thiết bị C9200-24PXG-A Catalyst 9200 24-port 8xmGig, 16x1G, PoE+, Network Advantage đã được gửi vào mail nhé.
Thiết bị chuyển mạch Switch Cisco C9200-24PXG-A Catalyst 9200 24 Ports (8 Ports multi Gigabit, 16 Ports 1 GE, PoE+) Network Advantage có hỗ trợ tính năng ACL nhé bạn
