Hardware specifications
|
|
Flash Memory
|
128 MB
|
|
DRAM
|
512 MB
|
|
CPU
|
APM86392 600 MHz dual core
|
|
Console ports
|
USB (Type B), Ethernet (RJ-45)
|
|
Storage interface
|
USB (Type A) for external flash storage
|
|
Network management interface
|
10/100 Mbps Ethernet (RJ-45)
|
|
Interface
|
24 10/100/1000 PoE+ Ethernet ports
|
|
Uplink interfaces
|
4 x 1Gb SFP
|
|
Performance and scalability
|
|
Forwarding bandwidth
|
108 Gbps
|
|
Switching bandwidth
|
216 Gbps
|
|
Maximum active VLANs
|
1023
|
|
VLAN IDs available
|
4096
|
|
Maximum Transmission Unit (MTU)-L3 packet
|
9198 bytes
|
|
Jumbo frame - Ethernet frame
|
9216 bytes
|
|
Forwarding rate: 64-byte Layer 3 packets
|
71.4 Mpps
|
|
Resource
|
|
Unicast MAC
|
16,000
|
|
ARP Entries
|
8000
|
|
IPv4 unicast direct routes
|
2000
|
|
IPv4 unicast indirect routes
|
1000
|
|
IPv6 unicast direct routes
|
2000
|
|
IPv6 unicast indirect routes
|
1000
|
|
IPv4 multicast routes and IGMP groups
|
1000
|
|
IPv6 multicast groups
|
1000
|
|
IPv4 QoS ACEs
|
500
|
|
IPv6 QoS ACEs
|
500
|
|
IPv4 security ACEs
|
600
|
|
IPv6 Security ACEs
|
600
|
| Voltage and power ratings |
|
Predicted reliability (MTBF in hours**)
|
324,280
|
|
Power rating
|
0.49 kVA
|
|
DC input voltages
|
12V - 3A / 53V - 8A
|
|
Input voltage and current
|
100 to 240 VAC/5A to 2A/50 to 60 Hz
|
|
Available PoE power
|
370W
|
|
Maximum number of PoE+
|
12 ports up to 30W
24 ports up to 15.4W
|
|
Dimensions
|
|
Inches (H x D x W)
|
1.75 x 14.5 x 17.5
|
|
Centimeters (H x D x W)
|
4.5 x 36.8 x 44.5
|
|
Pounds
|
12.8
|
|
Kilograms
|
5.8
|
|
Environmental ranges
|
|
Operating temperature up to 10,000 ft (3000 m)
|
23º to 113ºF / -5º to 45ºC
|
|
Operating altitude (Feet/Meters)
|
Up to 10,000/Up to 3000
|
|
Operating relative humidity
|
10% to 95% noncondensing
|
|
Safety and compliance (Safety)
|
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1
|
