FS-1048E Fortinet FortiSwitch 1048E 48x GE/10 GE SFP/SFP+ slots and 6x 40 GE QSFP+ or 4x 100 GE QSFP28

• Auto Discovery of Multiple Switches
• Number of Managed Switches per FortiGate: 8 to 256 Depending on FortiGate Model (Please refer to admin-guide) FortiLink Stacking (Auto Inter-Switch Links)
• Software Upgrade of Switches
• Centralized VLAN Configuration
• Switch POE Control
• Link Aggregation Configuration
• Spanning Tree Yes LLDP/MED
• IGMP Snooping
• L3 Routing and Services
• Policy-Based Routing
• Virtual Domain

• 802.1x Authentication (Port-based, MAC-Based, MAB)
• Syslog Collection
• DHCP Snooping
• Device Detection
• MAC Black/While Listing
• Policy Control of Users and Devices

• Firewall
• IPC, AV, Application Control, Botnet

• Support FortiLink FortiGate in HA Cluster
• LAG support for FortiLink Connection
• Active-Active Split LAG from FortiGate to FortiSwitches for Advanced Redundancy

• Jumbo Frames
• Auto-negotiation for port speed and duplex
• IEEE 802.1D MAC Bridging/STP
• IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
• IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
• STP Root Guard
• Edge Port / Port Fast
• IEEE 802.1Q VLAN Tagging
• Private VLAN
• IEEE 802.3ad Link Aggregation with LACP
• Unicast/Multicast traffic balance over trunking port (dst-ip, dst-mac, src-dst-ip, src-dst-mac, src-ip, src-mac)
• IEEE 802.1AX Link Aggregation
• Spanning Tree Instances (MSTP/CST) 15/1 15/1 15/1 15/1 IEEE 802.3x Flow Control and Back-pressure
• IEEE 802.1Qbb Priority-based Flow Control
•  IEEE 802.3z 1000Base-SX/LX
• IEEE 802.3ab 1000Base-T
• IEEE 802.3ae 10 Gigabit Ethernet
• IEEE 802.3 CSMA/CD Access Method and Physical Layer Specifications
• Storm Control
• MAC, IP, Ethertype-based VLANs
• Virtual-Wire

• Static Routing (Hardware-based)
• Routing Entries 16K
• L3 Host Entries 32K
• Dynamic Routing Protocols: OSPFv2, RIPv2, VRRP, BGP, ISIS
• Multicast Protocols PIM-SSM
• ECMP
• Bidirectional Forwarding Detection (BFD)
• DHCP Relay
• IGMP Snooping

• Port Mirroring
• Admin Authentication Via RFC 2865 RADIUS
• IEEE 802.1x authentication Port-based
• IEEE 802.1x Authentication MAC-based
• IEEE 802.1x Guest and Fallback VLAN
• IEEE 802.1x MAC Access Bypass (MAB)
• IEEE 802.1x Dynamic VLAN Assignment
• MAC-IP Binding
• sFlow
• ACL: 8K entries
• IEEE 802.1ab Link Layer Discovery Protocol (LLDP)
• IEEE 802.1ab LLDP-MED
• DHCP-Snooping
• Dynamic ARP Inspection
• Sticky MAC

• Multi-Chassis Link Aggregation (MCLAG)

• IEEE 802.1p Based Priority Queuing
• IP TOS/DSCP Based Priority Queuing

• IPv4 and IPv6 Management
• Telnet / SSH
• HTTP / HTTPS
• SNMP v1/v2c/v3
• SNTP
• Standard CLI and web GUI interface
• Software download/upload: TFTP/FTP/GUI
• Managed from FortiGate
• Support for HTTP REST APIs for Configuration and Monitoring

• RFC 2571 Architecture for Describing SNMP Framework
• DHCP Client
• RFC 854 Telnet Server
• RFC 2865 RADIUS
• RFC 1643 Ethernet-like Interface MIB
• RFC 1213 MIB-II
• RFC 1354 IP Forwarding Table MIB
• RFC 2572 SNMP Message Processing and Dispatching
• RFC 1573 SNMP MIB II
• RFC 1157 SNMPv1/v2c
• RFC 2030 SNTP

Product

SKU

Description

1 GE SFP LX transceiver module

FG-TRAN-LX

1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots

1 GE SFP RJ45 transceiver module

FG-TRAN-GC

1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+ slots

1 GE SFP SX transceiver module

FG-TRAN-SX

1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots

1 GE SFP RJ45 transceiver module

FS-TRAN-GC

1 GE SFP RJ45 transceiver module for systems with SFP/SFP+ slots

1 GE SFP SX transceivers, MMF, -40–85°C operation

FR-TRAN-SX

1 GE SFP SX transceiver module, -40–85°C, over MMF, for all systems with SFP and SFP/SFP+ slots

1 GE SFP LX transceivers, SMF, -40–85°C operation

FR-TRAN-LX

1 GE SFP LX transceiver module, -40–85°C, over SMF, for all systems with SFP and SFP/SFP+ slots

1 GE SFP transceivers, 90 km range, -40–85°C operation

FR-TRAN-ZX

1 GE SFP transceivers, -40–85°C operation, 90 km range for all systems with SFP slots

10 GE SFP+ transceiver module, short range

FG-TRAN-SFP+SR

10 GE SFP+ transceiver module, short range for all systems with SFP+ and SFP/SFP+ slots

10 GE XFP transceiver module, short range

FG-TRAN-XFPSR

10 GE XFP transceiver module, short range for all systems with XFP slots

10 GE SFP+ transceiver module, long range

FG-TRAN-SFP+LR

10 GE SFP+ transceiver module, long range for all systems with SFP+ and SFP/SFP+ slots

10 GE XFP transceiver module, long range

FG-TRAN-XFPLR

10 GE XFP transceiver module, long range for all systems with XFP slots

10 GE SFP+ active direct attach cable, 10m / 32.8 ft

SP-CABLE-ADASFP+

10 GE SFP+ active direct attach cable, 10m / 32.8 ft for all systems with SFP+ and SFP/SFP+ slots

10 GE copper SFP+ transceiver module, up to 30m

FS-TRAN-SFP+GC

10 GE copper SFP+ RJ45 transceiver, up to 30m

10 GE SFP+ transceiver module, short range

FS-TRAN-SFP+SR

10 GE SFP+ transceiver module, short range for SFP/SFP+ slots

10 GE SFP+ transceivers, extended range

FS-TRAN-SFP+ER

10 GE SFP+ transceiver module, extended range for Fortinet systems with SFP+ slots

10 GE SFP+ transceivers, long range multimode

FS-TRAN-SFP+LRM

10 GE SFP+ transceiver module, long range multimode for Fortinet systems with SFP+ slots

10 GE SFP+ passive direct attach cable

SP-CABLE-FS-SFP+1

10 GE SFP+ passive direct attach cable, 1 m for systems with SFP+ and SFP/SFP+ slots

10 GE SFP+ passive direct attach Cable

SP-CABLE-FS-SFP+3

10 GE SFP+ passive direct attach cable, 3 m for systems with SFP+ and SFP/SFP+ slots

10 GE SFP+ passive direct attach cable

SP-CABLE-FS-SFP+5

10 GE SFP+ passive direct attach cable, 5 m for systems with SFP+ and SFP/SFP+ slots

10 GE SFP+ passive direct attach cable

SP-CABLE-FS-SFP+7

10 GE SFP+ passive direct attach cable, 7 m for systems with SFP+ and SFP/SFP+ slot

40 GE QSFP+ transceivers, short range

FG-TRAN-QSFP+SR

40 GE QSFP+ transceivers, short range for all systems with QSFP+ slots

40 GE QSFP+ transceivers, short range, BiDi

FG-TRAN-QSFP+SR-BIDI

40 GE QSFP+ transceivers, short range BiDi for systems with QSFP+ slots

40 GE QSFP+ transceivers, long range

FG-TRAN-QSFP+LR

40 GE QSFP+ transceivers, long range for all systems with QSFP+ slots

40 GE QSFP+ to 4x 10 GE SFP+ optical breakout, 1 meter

FG-TRAN-QSFP-4XSFP

40 GE QSFP+ parallel breakout MPO to 4x LC connectors, 1 m reach, transceivers not included

40 GE QSFP+ to 4x 10 GE SFP+ optical breakout, 5 meter

FG-TRAN-QSFP-4SFP-5

40 GE QSFP+ parallel breakout MPO to 4x LC connectors, 5 m reach, transceivers not included

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+1

40 GE QSFP+ passive direct attach cable, 1 m for systems with QSFP+ slots

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+3

40 GE QSFP+ passive direct attach cable, 3 m for systems with QSFP+ slots

40 GE QSFP+ passive direct attach cable

SP-CABLE-FS-QSFP+5

40 GE QSFP+ passive direct attach cable, 5 m for systems with QSFP+ slots

100 GE CFP2 transceivers, long range

FG-TRAN-CFP2-LR4

100 GE CFP2 transceivers, long range, over single mode fiber, for all systems with CFP2 slots

100 GE CFP2 transceivers, short range

FG-TRAN-CFP2-SR10

100 GE CFP2 transceivers, 10 channel parallel fiber, short range for all systems with CFP2 slots

100 GE QSFP28 transceivers, short range

FG-TRAN-QSFP28-SR4

100 GE QSFP28 transceivers, 4 channel parallel fiber, short range for all systems with QSFP28 slots

100 GE QSFP28 transceivers, long range

FG-TRAN-QSFP28-LR4

100 GE QSFP28 transceivers, 4 channel parallel fiber, long range for all systems with QSFP28 slots

100 GE SR10 to 10x 10 GE fan out cable, 1 meter

FG-CABLE-SR10-SFP+

100 GE CFP2/QSFP28 parallel breakout MPO to 10x LC connectors, 1 m reach, transceivers not included

100 GE SR10 to 10x 10 GE fan out cable, 5 meter

FG-CABLE-SR10-SFP+5

100 GE CFP2/QSFP28 parallel breakout MPO to 10x LC connectors, 5 m reach, transceivers not included
