Ruckus ICX7450-48F ICX 7450 48 Ports SFP Switch with 3 Modular Slots

Name: ICX7450-48F
Brand: Ruckus
SKU: ICX7450-48F
Availability: InStock
Rating: 5 (1 reviews)

Ruckus Part Number : ICX7450-48F
List Price : $9,995
Bảo hành : 12 tháng
Made In : China
Stock : Liên hệ

Thiết bị chuyển mạch Switch Ruckus ICX7450-48F mang lại hiệu suất, tính linh hoạt và khả năng mở rộng cần thiết cho việc triển khai truy cập Gigabit Ethernet (GbE) của doanh nghiệp. Switch Ruckus ICX7450-48F cung cấp mật độ xếp chồng hàng đầu thị trường với tối đa 12 switch (cổng 576x 1 GbE và 144x 1/10 GbE) trên mỗi ngăn xếp.

View Datasheet ICX7450-48F

Ngoài ra, thiết bị mạng Switch Ruckus ICX7450-48F là giải pháp chuyển đổi có thể xếp chồng đầu tiên trong ngành để tận dụng các lợi thế của bảo mật VPN IPsec tại chỗ để đảm bảo tính toàn vẹn dữ liệu đầu cuối mà không cần các thiết bị mã hóa chuyên dụng.

Ruckus ICX7450-48F ICX 7450 48 Ports SFP Switch with 3 Modular Slots

Thông số kỹ thuật Switch Ruckus ICX7450-48F

Lưu ý: Các tính năng OSPF, VRRP, PIM, PBR, VRF yêu cầu phải active license ICX7450-PREM-LIC để sử dụng

Performance and Scalability
Switching capacity (data rate, full duplex)	336 Gbps
Forwarding capacity (data rate, full duplex)	250 Mpps
Fixed ports: 100/1000 Mbps SFP	48
Modular slots	3
Modular ports: 1 Gbps SFP (max.)	4
Modular ports: 1/10 GbE SFP/ SFP+ (max.)	12
Modular ports: 1/10GBASE-T RJ45 (max.)	12
Modular ports: 40 GbE QSFP+ (max.)	2
Modular service: IPsec VPN	With module
Base IPv4/v6 Layer 3 routing (RIP, static routing)	yes
Advanced IPv4/v6 Layer 3 routing (OSPF, BGP, VRRP, PIM, PBR, VRF)	With license
Aggregated stacking bandwidth	960 Gbps
Stacking density (maximum switches in a stack)	12
Stacking ports (maximum ports usable for stacking)	Up to 4×10 GbE SFP+ or 2×40 GbE QSFP+
Maximum stacking distance (distance between stacked switches)	10 km
Campus Fabric	Fabric Port Extender (PE)
Power
Power inlet (AC)	C14
Input voltage/frequency	AC: 100 to 240 VAC @ 50 to 60 Hz \| DC: 40 to 60 VDC
Maximum current draw (at 100 VAC, one power supply)	13.3 Amp
Power supply rated maximum output (AC)	2×250 W
Power supply rated maximum output (DC)	2×510 W
Switch power consumption3 (25°C) Idle (no PoE load) 10% traffic4 (full PoE load) 100% traffic4 (full PoE load)	119 W 120 W 123 W
Airflow	Reversible, front-to-back, or back-to-front
Switch heat dissipation (25°C)3 Idle (no PoE load) 10% traffic2 (full PoE load) 100% traffic2 (full PoE load)	406 BTU/hour 409 BTU/hour 420 BTU/hour
ENVIRONMENT
Net Weight (Kg)	6.8 kg (14.99 lb)
Dimensions (mm)	440 mm (17.323 in.) W × 393.7 mm (15.5 in.) D × 43.7 mm (1.720 in.) H; 1U
Acoustics (25°C, min fan speed)	46 dBA
MTBF (25°C)	576,586 hours
SPECIFICATIONS
Connector options	• 10/100/1000 Mbps, 10 Gbps 10GBASE-T ports: RJ-45 • 100 Mbps SFP ports • 1 Gbps SFP ports • 10 Gbps SFP+ ports • 40 Gbps QSFP+ ports • Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45 • Console management: Mini-USB RS232 serial port (Mini-B plug) • File Transfer: USB port, standard-A plug
DRAM	2 GB
NVRAM (Flash)	2 GB
Packet buffer size	8 MB
Maximum MAC addresses	32,768
Maximum VLANs Maximum PVLANs	• 4,095 • 32
Maximum STP (spanning trees instances)	254
Maximum VEs	255
Maximum routes (in hardware)	• 15,168 (IPv4) • 5,120 (IPv6) • 16,000 (Next Hop Addresses)
Trunking	• Maximum ports per trunk: 16 • Maximum trunk groups: 256
Maximum jumbo frame size	9,216 bytes
Average latency	1.3 μs
QoS priority queues	8 per port
IPsec performance	• Maximum throughput: 10 Gbps, full-duplex • Maximum tunnels: 100 (IPv4 and IPv6)
VRF	32
Multicast groups	• 8,192 (Layer 2) • 8,192 (Layer 3)
FEATURE SETS
Layer 2 feature set	• 802.1s Multiple Spanning Tree • 802.1x Authentication • Auto MDI/MDIX • BPDU Guard, Root Guard • Dual-Mode VLANs • MAC-based VLANs, Dynamic MAC-based VLAN activation • Dynamic Voice VLAN Assignment • Dynamic VLAN Assignment • Fast Port Span • GVRP: GARP VLAN Registration Protocol • IGMP Snooping (v1/v2/v3) • IGMP Proxy for Static Groups • IGMP v2/v3 Fast Leave • Inter-Packet Gap (IPG) adjustment • Link Fault Signaling (LFS) • MAC Address Filtering • MAC Learning Disable • MLD Snooping (v1/v2) • Multi-device Authentication • Per-VLAN Spanning Tree (PVST/PVST+/PVRST) • Mirroring - Port-based, ACL-based, MAC Filter-based, and VLAN-based • PIM-SM v2 Snooping • Port Loop Detection • Private VLAN • Remote Fault Notification (RFN) • Single-instance Spanning Tree • Trunk Groups (static, LACP) • Uni-Directional Link Detection (UDLD) • Metro-Ring Protocol (MRP) (v1, v2) • Virtual Switch Redundancy Protocol (VSRP) • Q-in-Q and selective Q-in-Q • VLAN Mapping • Topology Groups
Base Layer 3 IP routing	• IPv4 and IPv6 static routes − RIP v1/v2, RIPng • ECMP • Port-based Access Control Lists • Layer 3/Layer 4 ACLs • Host routes • Virtual interfaces • Routed interfaces • Route-only support • Routing between directly connected subnets
Premium Layer 3 IP routing (require license)	• IPv4 and IPv6 dynamic routes • OSPF v2, OSPF v3 (IPv6) • PIM-SM, PIM-SSM, PIM-DM, PIM passive (IPv4/IPv6 multicast routing functionality) • PBR • Virtual Route Redundancy Protocol VRRP v3 (IPv6) • VRRP-E (IPv4, IPv6) • BGP4, BGP4+ (IPv6) • GRE • IPv6 over IPv4 tunnels • VRF (IPv4 and IPv6) • MSDP
Quality of Service (QoS)	• ACL Mapping and Marking of ToS/DSCP • ACL Mapping and Marking of 802.1p • ACL Mapping to Priority Queue • Classifying and Limiting Flows Based on TCP Flags • DiffServ Support • Honoring DSCP and 802.1p • MAC Address Mapping to Priority Queue • Priority Queue Management using Weighted Round Robin (WRR), Strict Priority (SP), and a combination of WRR and SP • Priority Flow Control
Traffic management	• ACL-based inbound rate limiting and traffic policies • Broadcast, multicast, and unknown unicast rate limiting • Inbound rate limiting per port • Outbound rate limiting per port and per queue
Security	• IPsec 128/256 AES-GCM (with service module) • MACsec • 802.1X Authentication • MAC Authentication • Flexible authentication • Web authentication • DHCP snooping • Dynamic ARP inspection • Neighbor Discovery (ND) Inspection • Bi-level Access Mode (Standard- and EXEC-level) • EAP pass-through support • IEEE 802.1X username export in sFlow • Protection against Denial of Service (DoS) attacks • Authentication, Authorization, and Accounting (AAA) • MAC Address Locking MAC Port Security • Advanced Encryption Standard (AES) with SSHv2 • RADIUS/TACACS/TACACS+ • Secure Copy (SCP) • Secure Shell (SSHv2) • Protected Ports • Local Username/Password • Change of Authorization (CoA) RFC 5176 • RFC Conformance for Encryption: • RFC 5996 Internet Key Exchange Protocol Version 2 (IKEv2) • RFC 4303 IP Encapsulating Security Payload (ESP) • RFC 6379 Suite B Cryptographic Suites for IPsec (SuiteB-GCM-256 and Suite-B-GCM-128) • RFC 5903 Elliptic Curve Groups Modulo a Prime (ECP Groups) for IKEv2 • RFC 4868 Using HMAC-SHA-256, HMAC-SHA-384, and HMAC-SHA-512 with IPsec • RFC 4754 IKEv2 Authentication Using the Elliptic Curve Digital Signature Algorithm (ECDSA) • RFC 4106 The use of Galois/Counter Mode (GCM) in IPsec Encapsulating Security Payload (ESP)SP800-56A Recommendation for Pair-Wise Key Establishment Schemes Using Discrete Logarithm Cryptography • Encrypted Syslog (RFC 5425) • RADSEC (RFC 6614)
High availability (require license)	• Redundant hot-swappable power supplies • Hot-swappable fan trays • Layer 3 VRRP/VRRP-E protocol redundancy • Real-time state synchronization across the stack • Hitless failover and switchover from master to standby stack controller • Hot insertion and removal of stacked units • Layer 2 VSRP switch redundancy • In Service Software Update (ISSU)
SDN features	• Support for OpenFlow v1.0 and v1.3 • OpenFlow support with hybrid port mode • Operates with OpenDaylight SDN Controllers and the applications running on the controller
STANDARD COMPLIANCE
IEEE standards compliance	• 802.1AB LLDP • 802.1D MAC Bridging • 802.1p Mapping to Priority Queue • 802.1s Multiple Spanning Tree (MST) • 802.1w Rapid Reconfiguration of Spanning Tree • 802.1x Port-based Network Access Control (PNAC) • 802.3 Carrier Sense Multiple Access/Collision Detection (CSMA/CD) • 802.3ab 1000BASE-T • 802.1 AX-2008 Link Aggregation • 802.3ae 10 Gigabit Ethernet • 802.3af Power over Ethernet • 802.3at Power over Ethernet Plus • 802.3u 100Base-TX • 802.3x Full duplex and Flow Control • 802.3z 1000Base-SX/LX • 802.3 MAU MIB (RFC 2239) • 802.3ba 40 and 100 Gbps Ethernet • 802.1AE-MACsec (with license) • 802.3az Energy Efficient Ethernet • 802.1Q VLAN Tagging • 802.1BR Bridge Port Extension
ENVIRONMENT
Temperature	Operating temperature: −5°C to 50°C/23°F to 122°F Storage temperature: −40°C to 70°C/−40°F to 158°F
Humidity	Operating relative humidity: 10% to 90% at 50°C, non-condensing Non-operating relative humidity: 5% to 95% at 70°C, non-condensing
Altitude	Operating altitude: 10,000 ft (3,000 m) maximum Storage altitude: 39,000 ft (12,000 m) maximum
COMPLIANCE/CERTIFICATION
Electromagnetic emissions	FCC Class A (Part 15); EN 55022/CISPR-22 Class A; VCCI Class A; ICES-003 Electromagnetic Emission; AS/NZS 55022; EN 61000-3-2 Power Line Harmonics; EN 61000-3-3 Voltage Fluctuation and Flicker EN 61000-6-3 Emission Standard
Safety	CAN/CSA-C22.2 NO. 60950-1-07; UL 60950-1; IEC60950-1; EN 60950-1:2006 Safety of Information Technology Equipment; EN 60825-1 Safety of Laser Products
Immunity	EN 61000-6-1 Generic Immunity and Susceptibility; EN 55024 Immunity Characteristics; EN 61000-4-3 Radiated, Radio Frequency, Electromagnetic Field; EN 61000-4-4 Electrical Fast Transient; EN 61000-4-5 Surge; EN 61000-4-6 Conducted Disturbances Induced by Radio-Frequency Fields; EN 61000-4-8 Power Frequency Magnetic Field; EN 61000-4-11 Voltage Dips and Sags
Environmental regulatory compliance	RoHS-compliant (6 of 6); WEEE-compliant
Vibration	IEC 68-2-36, IEC 68-2-6
Shock and drop	IEC 68-2-27, IEC 68-2-32

Module quang sử dụng cho Switch Ruckus ICX7450-48F

Lưu ý: Module quang Ruckus 10G 40G được sử dụng khi lắp thêm các module ICX7400-4X10GF, ICX7400-1X40GQ

Part	Description	Data link	Stacking links
FAST ETHERNET OPTICS
E1MG-100FX-OM	100BASE-FX SFP optic MMF, LC connector, optical monitoring capable	√	x
E1MG-100FX-A	100BASE-FX SFP optic MMF, LC connector, optical monitoring capable, TAA compliant	√	x
E1MG-100FX-IR-OM	100BASE-FX IR SFP optic for SMF with LC connector, optical monitoring capable. For distances up to 15Km	√	x
E1MG-100FX-LR-OM	100BASE-FX LR SFP optic for SMF with LC connector, optical monitoring capable. For distances up to 40Km	√	x
1 GbE Fiber Optics
E1MG-SX-OM	1000BASE-SX SFP optic, MMF, LC connector, optical monitoring capable	√	x
E1MG-SX-OM-T	1000BASE-SX SFP optic, MMF, LC connector, optical monitoring capable, industrial temperature (-40°C to 85°C)	√	x
E1MG-SX-A	1000BASE-SX SFP Optic, MMF, (LC), TAA compliant	√	x
E1MG-LX-OM	1000BASE-LX SFP optic, SMF, LC connector, optical monitoring capable	√	x
E1MG-LX-OM-T	1000BASE-LX SFP optic, SMF, LC connector, optical monitoring capable, industrial temperature (-40°C to 85°C)	√	x
E1MG-LX-A	1000BASE-LX SFP Optic, SMF, LC connector, TAA compliant	√	x
E1MG-LHA-OM-T	1000BASE-LHA SFP optic, SMF, LC connector, optical monitoring capable, industrial temperature (-40°C to 85°C)	√	x
E1MG-BXD	1000BASE-BXD SFP optic SMF, transmits at 1490nm and receives at 1310nm, LC connector, single strand SMF fiber. This optic should only be connected to an E1MG-BXU at the far end.	√	x
E1MG-BXU	1000BASE-BXU SFP optic SMF, transmits at 1310nm and receives at 1490nm, LC connector, single strand SMF fiber. This optic should only be connected to an E1MG-BXD at the far end.	√	x
E1MG-TX	1000BASE-TX SFP Copper, RJ-45 connector	√	x
E1MG-TX-A	1000BASE-TX SFP Copper, RJ-45, TAA compliant	√	x
1G-SFP-TWX-0101	1GbE Direct Attach SFP to SFP active copper cable, 1m	√	x
1G-SFP-TWX-0501	1GbE Direct Attach SFP to SFP active copper cable, 5m	√	x
10 GbE Fiber Optics
10G-SFPP-USR	10GBASE-USR, SFP+ optic (LC), target range 100m over MMF	√	√
10G-SFPP-USR-SA	10GBASE-USR, SFP+ Optic (LC), Range 100m MMF, standard temperature (0°C to 70°C), TAA compliant	√	√
10G-SFPP-SR	10GBASE-SR, SFP+ optic (LC), target range 300m over MMF	√	√
10G-SFPP-SR-SA	10GBASE-SR, SFP+ optic (LC), target range 300m over MMF, standard temperature (0°C to 70°C), TAA compliant	√	√
10G-SFPP-SR-S	10GBASE-SR, SFPP MMF LC connector, standard temperature (0°C to 70°C)	√	√
10G-SFPP-LR	10GBASE-LR, SFP+ optic (LC), for up to 10Km over SMF	√	√
10G-SFPP-LR-SA	10GBASE-LR, SFP+ optic (LC), for up to 10Km over SMF, standard temperature (0°C to 70°C), TAA compliant	√	√
10G-SFPP-LR-S	10GBASE-LR, SFPP SMF (LC), for up to 10Km over SMF, standard temperature (0°C to 70°C)	√	√
10G-SFPP-ER	10GBASE-ER SFP+ optic (LC), for up to 40Km over SMF	√	x
10G-SFPP-ZR	10GBASE-ZR SFP+ optic (LC), for up to 80Km over SMF	√	x
10G-SFPP-LRM	10GBASE-LRM SFP+ optic (LC), for up to 220m over MMF	√	x
10G-SFPP-BXD-S	10GBASE-LR SFP+ Optic (LC) bidirectional downstream, standard temperature (0°C to 70°C)	√	√
10G-SFPP-BXU-S	10GBASE-LR SFP+ Optic (LC) bidirectional upstream, standard temperature (0°C to 70°C)	√	√
10G-SFPP-TWX-0101	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 1m	√	√
10G-SFPP-TWX-0108	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 1m, 8-pack	√	√
10G-SFPP-TWX-0301	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 3m	√	√
10G-SFPP-TWX-0308	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 3m, 8-pack	√	√
10G-SFPP-TWX-0501	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 5m	√	√
10G-SFPP-TWX-0508	10GbE Direct Attach SFP+ to SFP+ Active copper cable, 5m, 8-pack	√	√
10G-SFPP-TWX-P-0101	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 1m	√	√
10G-SFPP-TWX-P-0108	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 1m, 8-pack	√	√
10G-SFPP-TWX-P-0301	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 3m	√	√
10G-SFPP-TWX-P-0308	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 3m, 8-pack	√	√
10G-SFPP-TWX-P-0501	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 5m	√	√
10G-SFPP-TWX-P-0508	10GbE Direct Attach SFP+ to SFP+ Passive copper cable, 5m, 8-pack	√	√
10GE-SFPP-AOC-0701	10GbE Direct Attach SFP+ to SFP+ Active Optical Cable, 7m	√	√
10GE-SFPP-AOC-1001	10GbE Direct Attach SFP+ to SFP+ Active Optical Cable, 10m	√	√
40 GbE Fiber Optics
E40G-QSFP-SR4	40GBASE-SR4 QSFP+ optic (MTP 1×8 or 1×12), 100m over MMF OM3. 150m over MMF OM4	√	√
E40G-QSFP-ESR4	40GBASE-ESR4 QSFP+ optic (MTP 1x8 or 1x12), 300m over MMF	√	x
E40G-QSFP-LR4	40GBASE-LR4 QSFP+ optic (LC), for up to 10Km over SMF	√	√
E40G-QSFP-LM4	40GBASE-LM4 QSFP+, 1310nm, 160m over duplex LC OM4 MMF	√	x
E40G-QSFP-ER4	40GBASE-ER4 QSFP+ optic (LC), for up to 40Km over SMF	√	x
E40G-QSFP-SR-BIDI	40GbE SR QSFP+ optic (LC), bidirectional, 100m over OM3 MMF	√	x
E40G-QSFP-QSFP-C-0101	40GbE Direct Attach QSFP+ to QSFP+ Active Copper cable, 1m	√	√
E40G-QSFP-QSFP-C-0301	40GbE Direct Attach QSFP+ to QSFP+ Active Copper cable, 3m	√	√
E40G-QSFP-QSFP-C-0501	40GbE Direct Attach QSFP+ to QSFP+ Active Copper cable, 5m	√	√
E40G-QSFP-C-0101	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 1m	√	√
E40G-QSFP-C-0501	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 5m	√	x
40G-QSFP-C-00501	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 0.5m	√	√
40G-QSFP-C-00508	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 0.5m, 8-pack	√	√
E40G-QSFP-QSFP-P-0101	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 1m	√	√
E40G-QSFP-QSFP-P-0301	40GbE Direct Attach QSFP+ to QSFP+ Passive Copper Cable, 3m	√	√
E40G-QSFP-QSFP-AOC-1001	40GbE Direct Attach QSFP+ to QSFP+ Active Optical Cable, 10m	√	x

License cho Switch Ruckus ICX7450-48F

ICX7450-PREM-LIC	Ruckus ICX 7450 Layer 3 Premium Software License.
ICX-MACSEC-LIC	License to enable MACsec encryption.

Module card sử dụng cho Switch Ruckus ICX7450-48F

ICX7400-4X1GF	Ruckus ICX 7450 4-port 100 Mbps/1 GbE SFP module
ICX7400-4X10GF	Ruckus ICX 7450 4-port 1/10 GbE SFP/SFP+ module (for stacking or uplinks)
ICX7400-4X10GC	Ruckus ICX 7450 4-port 1/10 GbE 10GBASE-T copper module
ICX7400-1X40GQ	Ruckus ICX 7450 1-port 40 GbE QSFP+ module (for stacking or uplink)
ICX7400-SERVICE-MOD	Ruckus ICX 7450 Service Module for IPsec VPN encryption

Option cho Switch Ruckus ICX7450-48F

RPS15-E	Ruckus ICX 7450/6610 non-PoE 250 W AC power supply with front-to-back airflow
RPS15-I	Ruckus ICX 7450/6610 non-PoE 250 W AC power supply with back-to-front airflow.
RPS16DC-E	Ruckus ICX 7450/6610 PoE 510 W DC power supply with front-to-back airflow.
RPS16DC-I	Ruckus ICX 7450/6610 PoE 510 W DC power supply with back-to-front airflow.
ICX-FAN10-E	Ruckus ICX 7450 front-to-back airflow fan
ICX-FAN10-I	Ruckus ICX 7450 back-to-front airflow fan
ICX7000-RMK	FRU, rack mount kit, two post, Ruckus ICX 7750/7450.
XBR-R000295	FRU, rack mount kit, four post, 24 in. to 32 in. depth rack
