Switch Cisco WS-C2960X-24TD-L Catalyst 2960-X 24 Ports 10/100/1000 Ethernet, 2 x 10G SFP+ Uplink, LAN Base
Mã sản phẩm: WS-C2960X-24TD-L
Cisco Part Number : WS-C2960X-24TD-L Switch Cisco 2960X WS-C2960X-24TD-L là thiết bị chuyển mạch Gigabit Ethernet có cấu hình cố định, cung cấp khả năng truy cập cấp doanh nghiệp cho các ứng dụng trong các doanh nghiệp hoặc trường học. Switch Cisco 2960X WS-C2960X-24TD-L cung cấp khả năng tích hợp, cấu hình, theo dõi và khắc phục sự cố thiết bị dễ dàng. Thiết bị mạng Cisco 2960X WS-C2960X-24TD-L được thiết kế để phù hợp với lớp Accees (lớp truy nhập mạng đầu cuối) với chi phí đầu tư là thấp trong dòng Switch 2960X Series. Switch Cisco WS-C2960X-24TD-L cung cấp 24 cổng Giga 10/100/1000 Mps Base-T với 02 Uplink GE SFP+ để kết nối đường quang Multimode hoặc Single Mode. WS-C2960X-24TD-L sử dụng điện AC 220V. Hardware specifications Flash Memory 128 MB DRAM 512 MB CPU APM86392 600 MHz dual core Console ports USB (Type B), Ethernet (RJ-45) Storage interface USB (Type A) for external flash storage Network management interface 10/100 Mbps Ethernet (RJ-45) Interface 24 10/100/1000 Ethernet ports Uplink interfaces 2 x 10Gb SFP+ Performance and scalability Forwarding bandwidth 108 Gbps Switching bandwidth 216 Gbps Maximum active VLANs 1023 VLAN IDs available 4096 Maximum Transmission Unit (MTU)-L3 packet 9198 bytes Jumbo frame - Ethernet frame 9216 bytes Forwarding rate: 64-byte Layer 3 packets 95.2 Mpps Resource Unicast MAC 16,000 ARP Entries 8000 IPv4 unicast direct routes 2000 IPv4 unicast indirect routes 1000 IPv6 unicast direct routes 2000 IPv6 unicast indirect routes 1000 IPv4 multicast routes and IGMP groups 1000 IPv6 multicast groups 1000 IPv4 QoS ACEs 500 IPv6 QoS ACEs 500 IPv4 security ACEs 600 IPv6 Security ACEs 600 Predicted reliability (MTBF in hours**) 569,520 Power rating 0.034 kVA DC input voltages 12V - 3A / 53V - N/A Input voltage and current 100 to 240 VAC/1A to 0.5A/50 to 60 Hz Dimensions Inches (H x D x W) 1.75 x 11.0 x 17.5 Centimeters (H x D x W) 4.5 x 27.9 x 44.5 Pounds 8.9 Kilograms 4.0 Environmental ranges Operating temperature up to 10,000 ft (3000 m) 23º to 113ºF / -5º to 45ºC Operating altitude (Feet/Meters) Up to 10,000/Up to 3000 Operating relative humidity 10% to 95% noncondensing Safety and compliance (Safety) UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector GLC-TE Module quang Cisco GLC-TE 1000BASE-T, RJ-45 connector Module quang Cisco GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC Module quang Cisco GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC Module quang Cisco GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC Module quang Cisco GLC-ZX-MMD 1000BASE-ZX, SMF, DOM, 1550 nm, 80km, Dual LC Module quang Cisco GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC Module quang Cisco GLC-LH-SM 1000BASE-LX/LH, MMF/SMF, 1310 nm, 10km, Dual LC Module quang Cisco GLC-ZX-SM 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1490TX 1310RX, Single LC Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1310TX 1490RX, Single LC Module quang Cisco 1000BASE-BX40 SFP, 1550NM Module quang Cisco 1000BASE-BX40 SFP, 1310NM Module quang Cisco 1000BASE-BX40 SFP, 1490NM Module quang Cisco 1000BASE-BX80 SFP, 1570NM Module quang Cisco 1000BASE-BX80 SFP, 1490NM Module quang Cisco GLC-2BX-D 1000BASE-BX10, SMF, 1310TX 1490RX, 2 single LC/PC Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector SFP-GE-S Module quang CiscoSFP-GE-S 1000BASE-SX, MMF, DOM, 850 nm, 550m SFP-GE-L Module quang Cisco SFP-GE-L 1000BASE-LX/LH, MMF/SMF DOM, 1300 nm, 10km, Dual LC SFP-GE-Z Module quang Cisco SFP-GE-Z 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC GLC-SX-MM-RGD Module quang Cisco GLC-SX-MM-RGD 1000BASE-SX, MMF, 850 nm, 550m, Dual LC, industrial GLC-LX-SM-RGD Module quang Cisco GLC-LX-SM-RGD 1000BASE-LX/LH, MMF/SMF, 1300 nm, 10km, Dual LC, industrial GLC-ZX-SM-RGD Module quang Cisco GLC-ZX-SM-RGD 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC, industrial SFP-GPON-B Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX SFP-GPON-C Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX SFP-GPON-B-I Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX, industrial SFP-GPON-C-I Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX, industrial 10GBASE-SR SFP Module, Enterprise-Class 10GBASE-SR SFP Module 10GBASE-LR SFP Module, Enterprise-Class 10GBASE-LRM SFP Module 10GBASE-LR SFP Module 10GBASE-ER SFP Module, Enterprise-Class Cisco 10GBASE-ER SFP+ Module for SMF 10GBASE-ZR SFP Module, Enterprise-Class Cisco 10GBASE-ZR SFP10G Module for SMF SFP-10G-BXU-I= SFP+ Bidirectional for 10km, upstream SFP-10G-BXD-I= SFP+ Bidirectional for 10km, downstream SFP+ Bidirectional for 40km, upstream SFP+ Bidirectional for 40km, downstream 10GBASE Active Optical SFP+ Cable, 7M 10GBASE Active Optical SFP+ Cable, 5M 10GBASE Active Optical SFP+ Cable, 3M 10GBASE Active Optical SFP+ Cable, 2M 10GBASE Active Optical SFP+ Cable, 1M 10GBASE Active Optical SFP+ Cable, 10M Part Number Description FlexStack-Plus hot-swappable stacking module C2960X-FIBER-STK FlexStack-Extended Fiber stacking module C2960X-HYBRID-STK FlexStack-Extended Hybrid module, with one copper and one fiber port CAB-STK-E-0.5M Stacking cable with a 0.5 m length CAB-STK-E-1M Stacking cable with a 1.0 m length CAB-STK-E-3M Stacking cable with a 3.0 m lengthSwitch Cisco WS-C2960X-24TD-L Catalyst 2960-X 24 GigE, 2 x 10G SFP+, LAN Base
Cisco Spare Part Number : WS-C2960X-24TD-L=
List Price : $3,795
Bảo hành : 12 tháng
Made In : ASIA/EU/US
View Datasheet
Thông số kỹ thuật chi tiết của WS-C2960X-24TD-L
Voltage and power ratings
Các module quang dưới đây có thể sử dụng cho Switch WS-C2960X-24TD-L:
Các module quang 1G Cisco cho WS-C2960X-24TD-L:
Các module quang 10G Cisco dùng cho WS-C2960X-24TD-L:
Các module quang OEM cho WS-C2960X-24TD-L:
Part
Depcription
GLC-LH-SMD-CL
OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MMD-CL
OEM GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC
GLC-EX-SMD-CL
OEM GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC
GLC-T-CL
OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL
OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL
OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MM-CL
OEM GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC
Các Stack Module, Stack dùng cho Switch Cisco C2960X – C2960XR:
