Switch Cisco WS-C2960X-48TD-L Catalyst 2960-X 48 Ports GigE, 2 x 10G SFP+, LAN Base

Cisco Part Number : WS-C2960X-48TD-L
Cisco Spare Part Number : WS-C2960X-48TD-L=
List Price : $5,595
Bảo hành : 12 tháng
Made In : ASIA/EU/US

Switch Cisco 2960X WS-C2960X-48TD-L là thiết bị chuyển mạch Gigabit Ethernet có cấu hình cố định, cung cấp khả năng truy cập cấp doanh nghiệp cho các ứng dụng trong các doanh nghiệp hoặc trường học. Switch Cisco 2960X WS-C2960X-48TD-L cung cấp khả năng tích hợp, cấu hình, theo dõi và khắc phục sự cố thiết bị dễ dàng.

View Datasheet

Switch Cisco 2960X WS-C2960X-48TD-L được thiết kế để phù hợp với lớp Accees (lớp truy nhập mạng đầu cuối) với chi phí đầu tư là thấp trong dòng Switch 2960X Series. Switch Cisco WS-C2960X-48TD-L cung cấp 48 cổng Giga 10/100/1000 Mps Base-T với 02 Uplink GE SFP+ để kết nối đường quang Multimode hoặc Single Mode. WS-C2960X-48TD-L sử dụng điện AC 220V.

Switch Cisco WS-C2960X-48TD-L Catalyst 2960-X 48 GigE, 2 x 10G SFP+, LAN Base

Thông số kỹ thuật chi tiết của WS-C2960X-48TD-L:

Hardware specifications
Flash Memory	128 MB
DRAM	512 MB
CPU	APM86392 600 MHz dual core
Console ports	USB (Type B), Ethernet (RJ-45)
Storage interface	USB (Type A) for external flash storage
Network management interface	10/100 Mbps Ethernet (RJ-45)
Interface	48 10/100/1000 Ethernet ports
Uplink interfaces	2 x 10Gb SFP+
Performance and scalability
Forwarding bandwidth	108 Gbps
Switching bandwidth	216 Gbps
Maximum active VLANs	1023
VLAN IDs available	4096
Maximum Transmission Unit (MTU)-L3 packet	9198 bytes
Jumbo frame - Ethernet frame	9216 bytes
Forwarding rate: 64-byte Layer 3 packets	130.9 Mpps
Resource
Unicast MAC	16,000
ARP Entries	8000
IPv4 unicast direct routes	2000
IPv4 unicast indirect routes	1000
IPv6 unicast direct routes	2000
IPv6 unicast indirect routes	1000
IPv4 multicast routes and IGMP groups	1000
IPv6 multicast groups	1000
IPv4 QoS ACEs	500
IPv6 QoS ACEs	500
IPv4 security ACEs	600
IPv6 Security ACEs	600
Voltage and power ratings
Predicted reliability (MTBF in hours**)	445,460
Power rating	0.049 kVA
DC input voltages	12V - 4A / 53V - N/A
Input voltage and current	100 to 240 VAC/1A to 0.5A/50 to 60 Hz
Dimensions
Inches (H x D x W)	1.75 x 11.0 x 17.5
Centimeters (H x D x W)	4.5 x 27.9 x 44.5
Pounds	9.6
Kilograms	4.3
Environmental ranges
Operating temperature up to 10,000 ft (3000 m)	23º to 113ºF / -5º to 45ºC
Operating altitude (Feet/Meters)	Up to 10,000/Up to 3000
Operating relative humidity	10% to 95% noncondensing
Safety and compliance (Safety)	UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1

Các module quang dưới đây có thể sử dụng cho Switch WS-C2960X-48TD-L:

Các module quang 1G Cisco cho WS-C2960X-48TD-L:

GLC-T	Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector
GLC-TE	Module quang Cisco GLC-TE 1000BASE-T, RJ-45 connector
GLC-SX-MMD	Module quang Cisco GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC
GLC-LH-SMD	Module quang Cisco GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-EX-SMD	Module quang Cisco GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC
GLC-ZX-SMD	Module quang Cisco GLC-ZX-MMD 1000BASE-ZX, SMF, DOM, 1550 nm, 80km, Dual LC
GLC-SX-MM	Module quang Cisco GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC
GLC-LH-SM	Module quang Cisco GLC-LH-SM 1000BASE-LX/LH, MMF/SMF, 1310 nm, 10km, Dual LC
GLC-ZX-SM	Module quang Cisco GLC-ZX-SM 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC
GLC-BX-D	Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1490TX 1310RX, Single LC
GLC-BX-U	Module quang Cisco GLC-BX-D 1000BASE-BX, SMF, 1310TX 1490RX, Single LC
GLC-BX40-D-I	Module quang Cisco 1000BASE-BX40 SFP, 1550NM
GLC-BX40-U-I	Module quang Cisco 1000BASE-BX40 SFP, 1310NM
GLC-BX40-DA-I	Module quang Cisco 1000BASE-BX40 SFP, 1490NM
GLC-BX80-D-I	Module quang Cisco 1000BASE-BX80 SFP, 1570NM
GLC-BX80-U-I	Module quang Cisco 1000BASE-BX80 SFP, 1490NM
GLC-2BX-D	Module quang Cisco GLC-2BX-D 1000BASE-BX10, SMF, 1310TX 1490RX, 2 single LC/PC
SFP-GE-T	Module quang Cisco GLC-T 1000BASE-T, RJ-45 connector
SFP-GE-S	Module quang CiscoSFP-GE-S 1000BASE-SX, MMF, DOM, 850 nm, 550m
SFP-GE-L	Module quang Cisco SFP-GE-L 1000BASE-LX/LH, MMF/SMF DOM, 1300 nm, 10km, Dual LC
SFP-GE-Z	Module quang Cisco SFP-GE-Z 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC
GLC-SX-MM-RGD	Module quang Cisco GLC-SX-MM-RGD 1000BASE-SX, MMF, 850 nm, 550m, Dual LC, industrial
GLC-LX-SM-RGD	Module quang Cisco GLC-LX-SM-RGD 1000BASE-LX/LH, MMF/SMF, 1300 nm, 10km, Dual LC, industrial
GLC-ZX-SM-RGD	Module quang Cisco GLC-ZX-SM-RGD 1000BASE-ZX, SMF, 1550 nm, 80km, Dual LC, industrial
SFP-GPON-B	Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX
SFP-GPON-C	Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX
SFP-GPON-B-I	Module quang SFP-GPON-B GPON Class B+ SFP OLT, 1490TX 1310RX, industrial
SFP-GPON-C-I	Module quang SFP-GPON-C GPON Class C+ SFP OLT 1490TX 1310RX, industrial

Các module quang 10G Cisco dùng cho WS-C2960X-48TD-L:

SFP-10G-SR-S	10GBASE-SR SFP Module, Enterprise-Class
SFP-10G-SR	10GBASE-SR SFP Module
SFP-10G-LR-S	10GBASE-LR SFP Module, Enterprise-Class
SFP-10G-LRM	10GBASE-LRM SFP Module
SFP-10G-LR	10GBASE-LR SFP Module
SFP-10G-ER-S	10GBASE-ER SFP Module, Enterprise-Class
SFP-10G-ER	Cisco 10GBASE-ER SFP+ Module for SMF
SFP-10G-ZR-S	10GBASE-ZR SFP Module, Enterprise-Class
SFP-10G-ZR	Cisco 10GBASE-ZR SFP10G Module for SMF
SFP-10G-BXU-I=	SFP+ Bidirectional for 10km, upstream
SFP-10G-BXD-I=	SFP+ Bidirectional for 10km, downstream
SFP-10G-BX40U-I	SFP+ Bidirectional for 40km, upstream
SFP-10G-BX40D-I	SFP+ Bidirectional for 40km, downstream
SFP-10G-AOC7M	10GBASE Active Optical SFP+ Cable, 7M
SFP-10G-AOC5M	10GBASE Active Optical SFP+ Cable, 5M
SFP-10G-AOC3M	10GBASE Active Optical SFP+ Cable, 3M
SFP-10G-AOC2M	10GBASE Active Optical SFP+ Cable, 2M
SFP-10G-AOC1M	10GBASE Active Optical SFP+ Cable, 1M
SFP-10G-AOC10M	10GBASE Active Optical SFP+ Cable, 10M

Các module quang OEM cho WS-C2960X-48TD-L:

Part	Depcription
GLC-LH-SMD-CL	OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MMD-CL	OEM GLC-SX-MMD 1000BASE-SX, MMF, DOM, 850 nm, 550m, Dual LC
GLC-EX-SMD-CL	OEM GLC-EX-SMD 1000BASE-EX, SMF, DOM, 1310 nm, 40km, Dual LC
GLC-T-CL	OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL	OEM GLC-T 1000BASE-T, RJ-45 connector
GLC-LH-SM-CL	OEM GLC-LH-SMD 1000BASE-LX/LH, MMF/SMF DOM, 1310 nm, 10km, Dual LC
GLC-SX-MM-CL	OEM GLC-SX-MM 1000BASE-SX, MMF, 850 nm, 550m, Dual LC

Các Stack Module, Stack dùng cho Switch Cisco C2960X – C2960XR

Part Number	Description
C2960X-STACK	FlexStack-Plus hot-swappable stacking module
C2960X-FIBER-STK	FlexStack-Extended Fiber stacking module
C2960X-HYBRID-STK	FlexStack-Extended Hybrid module, with one copper and one fiber port
CAB-STK-E-0.5M	Stacking cable with a 0.5 m length
CAB-STK-E-1M	Stacking cable with a 1.0 m length
CAB-STK-E-3M	Stacking cable with a 3.0 m length
