| Hardware Specifications |
| 10/100/1000 Ethernet Ports |
48 |
| Fixed Uplinks |
2 x 10 Gigabit Ethernet with SFP+ and 2 x 1 Gigabit Ethernet with SFP |
| Default AC Power Supply |
250 WAC |
| Available PoE Power |
775W |
| Performance Specifications |
|
Switching capacity
|
176 Gbps
|
|
Stacking bandwidth
|
160 Gbps
|
|
Total number of MAC addresses
|
32,000
|
|
Total number of IPv4 routes (ARP plus learned routes)
|
24,000
|
|
FNF entries
|
24,000 flows
|
|
DRAM
|
4 GB
|
|
Flash
|
2 GB
|
|
VLAN IDs
|
4,094
|
|
Total switched virtual interfaces (SVIs)
|
1,000
|
|
Jumbo frame
|
9198 bytes
|
|
Total routed ports per 3650 stack
|
208
|
|
Wireless
|
|
Number of access points per switch/stack
|
25
|
|
Number of wireless clients per switch/stack
|
1000
|
|
Total number of WLANs per switch
|
64
|
|
Wireless bandwidth per switch
|
Up to 40 Gbps
|
|
Supported Aironet access point series
|
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
|
|
Forwarding Rate
|
104.16 Mpps
|
|
Dimensions
|
|
Dimensions (H x W x D) (Inches/Centimeters)
|
1.73 x 17.5 x 19.125/ 4.4 x 44.5 x 48.6
|
|
Weight (Pounds/Kilograms)
|
17.20/7.80
|
|
MTBF Hours
|
383,760
|
|
Environmental Ranges
|
|
With AC Power Supply
Operating Environment and Altitude
|
-5ºC to +45ºC, up to 5000 feet (1500m)
-5ºC to +40ºC, up to 10,000 feet (3000m)
-5ºC to +35ºC, up to 13,000 feet (4000m)
-5ºC to +30ºC, up to 16,400 feet (5000m)
|
|
With DC Power Supply
Operating Environment and Altitude (NEBS)
|
-5ºC to +45ºC, up to 6000 feet (1800m)
-5ºC to +40ºC, up to 10,000 feet (3000m)
-5ºC to +35ºC, up to 13,000 feet (4000m)
-5ºC to +30ºC, up to 16,400 feet (5000m)
|
| Safety and Compliance |
|
Safety Certifications
|
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, GOST, NOM (obtained by partners and distributors)
|
|
Electromagnetic Emissions Certifications
|
47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A), AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2 ,EN61000-3-3, KN22 Class A, KCC, CNS13438 Class A, EN55024, CISPR24, KN24
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
Bạn đang cần tư vấn về sản phẩm: WS-C3650-48FD-L ?
Chào anh,
Sản phẩm Switch Cisco WS-C3650-48FD-L có tổng mức PoE là 775W, hiện vẫn đang còn hàng trong kho. Anh vui lòng cung cấp thông tin liên hệ hoặc liên hệ Hotline: 0906 051 599 để được tư vấn tốt nhất.
Bạn vui lòng liên hệ hotline 0962 052 874 để được báo giá tốt nhất nhé
Bạn vui lòng liên hệ hotline 0962 052 874 để được báo giá tốt nhất nhé
Bạn vui lòng liên hệ hotline 0962 052 874 để được báo giá tốt nhất nhé
Switch Cisco WS-C3650-48FD-L Catalyst 3650 Stacking 48 Ports 10/100/1000 PoE+ 775W and 2x10G Uplink ports, 1025WAC PSU, 1 RU, LAN Base 2 cổng uplink quang 10G bạn nhé
