Hardware Specifications
|
|
10/100/1000 Ethernet Ports
|
48 PoE+
|
|
Fixed Uplinks
|
4 x 10 Gigabit Ethernet with SFP+ or 4 x Gigabit Ethernet with SFP
|
|
Default AC Power Supply
|
640 WAC
|
|
Available PoE Power
|
390 W
|
|
Performance Specifications
|
|
Switching capacity
|
176 Gbps
|
|
Stacking bandwidth
|
160 Gbps
|
|
Total number of MAC addresses
|
32,000
|
|
Total number of IPv4 routes (ARP plus learned routes)
|
24,000
|
|
FNF entries
|
48,000 flows
|
|
DRAM
|
4 GB
|
|
Flash
|
2 GB
|
|
VLAN IDs
|
4,094
|
|
Total switched virtual interfaces (SVIs)
|
1,000
|
|
Jumbo frame
|
9198 bytes
|
|
Total routed ports per 3650 stack
|
208
|
|
Wireless
|
|
Number of access points per switch/stack
|
25
|
|
Number of wireless clients per switch/stack
|
1000
|
|
Total number of WLANs per switch
|
64
|
|
Wireless bandwidth per switch
|
Up to 40 Gbps
|
|
Supported Aironet access point series
|
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
|
|
Forwarding Rate
|
130.95 Mpps
|
|
Dimensions
|
|
Dimensions (H x W x D) (Inches/Centimeters)
|
1.73 x 17.5 x 17.625/4.4 x 44.5 x 44.8
|
|
Weight (Pounds/Kilograms)
|
16.75/7.60
|
|
MTBF Hours
|
383,760
|
|
Environmental Ranges
|
|
With AC Power Supply
Operating Environment and Altitude
|
-5ºC to +45ºC, up to 5000 feet (1500m)
-5ºC to +40ºC, up to 10,000 feet (3000m)
-5ºC to +35ºC, up to 13,000 feet (4000m)
-5ºC to +30ºC, up to 16,400 feet (5000m)
|
|
With DC Power Supply
Operating Environment and Altitude (NEBS)
|
-5ºC to +45ºC, up to 5000 feet (1500m)
-5ºC to +45ºC, up to 10,000 feet (3000m)
|
|
Safety and Compliance
|
|
Safety Certifications
|
UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition
EN 60950-1 Second Edition
IEC 60950-1 Second Edition
GOST
NOM (obtained by partners and distributors)
|
|
Electromagnetic Emissions Certifications
|
47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
KCC
CNS13438 Class A
EN55024
CISPR24
KN24
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
Bạn đang cần tư vấn về sản phẩm: WS-C3650-48PQ-E ?
Băng thông chuyển mạch của thiết bị mạng WS-C3650-48PQ-E Cisco Catalyst 3650 48 Ports GE PoE+ 4x10G Uplink IP Services là 176 Gbps anh chị nhé
Không thể dùng stack WS-C3650-48PQ-E Cisco Catalyst 3650 48 Ports GE PoE+ 4x10G Uplink IP Services với WS-C3650-24TD-L anh chị nhé, chỉ có thể stack cùng mã với nhau
WS-C3650-48PQ-E Cisco Catalyst 3650 48 Ports GE PoE+ 4x10G Uplink IP Services có tính năng ACL anh chị nhé
WS-C3650-48PQ-E Cisco Catalyst 3650 48 Ports GE PoE+ 4x10G Uplink IP Services có tính năng chống giả mạo DHCP anh chị nhé
Có thể quản lý Cisco Catalyst 3650 series bằng Cisco IOS Software CLI, web GUI, Cisco Prime Infrastructure 2.0.1 hoặc Cisco Network Assistant Software ạ.
