| Hardware Specifications |
| 10/100/1000 Ethernet Ports |
48 |
| Fixed Uplinks |
2 x 10 Gigabit Ethernet with SFP+ and 2 x 1 Gigabit Ethernet with SFP |
| Default AC Power Supply |
250 WAC |
| Available PoE Power |
- |
| Performance Specifications |
|
Switching capacity
|
176 Gbps
|
|
Stacking bandwidth
|
160 Gbps
|
|
Total number of MAC addresses
|
32,000
|
|
Total number of IPv4 routes (ARP plus learned routes)
|
24,000
|
|
FNF entries
|
48000 flows
|
|
DRAM
|
4 GB
|
|
Flash
|
2 GB
|
|
VLAN IDs
|
4,094
|
|
Total switched virtual interfaces (SVIs)
|
1,000
|
|
Jumbo frame
|
9198 bytes
|
|
Total routed ports per 3650 stack
|
208
|
|
Wireless
|
|
Number of access points per switch/stack
|
25
|
|
Number of wireless clients per switch/stack
|
1000
|
|
Total number of WLANs per switch
|
64
|
|
Wireless bandwidth per switch
|
Up to 40 Gbps
|
|
Supported Aironet access point series
|
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040
|
|
Forwarding Rate
|
104.16 Mpps
|
|
Dimensions
|
|
Dimensions (H x W x D) (Inches/Centimeters)
|
1.73 x 17.5 x 17.625 / 4.4 x 44.5 x 44.8
|
|
Weight (Pounds/Kilograms)
|
15.90/7.21
|
|
MTBF Hours
|
527,580
|
|
Environmental Ranges
|
|
With AC Power Supply
Operating Environment and Altitude
|
-5ºC to +45ºC, up to 5000 feet (1500m)
-5ºC to +40ºC, up to 10,000 feet (3000m)
-5ºC to +35ºC, up to 13,000 feet (4000m)
-5ºC to +30ºC, up to 16,400 feet (5000m)
|
|
With DC Power Supply
Operating Environment and Altitude (NEBS)
|
-5ºC to +45ºC, up to 6000 feet (1800m)
-5ºC to +40ºC, up to 10,000 feet (3000m)
-5ºC to +35ºC, up to 13,000 feet (4000m)
-5ºC to +30ºC, up to 16,400 feet (5000m)
|
| Safety and Compliance |
|
Safety Certifications
|
UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, GOST, NOM (obtained by partners and distributors)
|
|
Electromagnetic Emissions Certifications
|
47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A), AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2 ,EN61000-3-3, KN22 Class A, KCC, CNS13438 Class A, EN55024, CISPR24, KN24
|
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
Bạn đang cần tư vấn về sản phẩm: WS-C3650-48TD-S ?
Chào anh,
Sản phẩm Switch Cisco WS-C3650-48TD-S cung cấp 2 cổng quang 10 Gigabit Ethernet SFP+ để Uplink, anh có thể mua thêm module quang 10GE để sử dụng.
Thông tin đến anh!
Thiết bị chuyển mạch Cisco WS-C3650-48TD-S sử dụng nguồn 250W, CNTTShop đã gửi báo giá nguồn PWR-C2-250WAC qua email, anh check inbox nhé.
CNTTShop đã gửi báo giá switch Cisco WS-C3650-48TD-S qua email, anh vui lòng check inbox nhé.
Thiết bị chuyển mạch Cisco WS-C3650-48TD-S được bảo hành chính hãng 1 năm anh nhé.
Switch Cisco WS-C3650-48TD-S sử dụng nguồn rời có thể thay thế hoặc nâng cấp chị nhé.
