| Performance |
| Switching capacity |
176 Gbps |
| Stacking bandwidth |
480 Gbps |
| Total number of MAC addresses |
32,000 |
| Total number of IPv4 routes (ARP plus learned routes) |
24,000 |
| FNF entries |
48,000 flow |
| DRAM |
4 GB |
| Flash |
2 GB |
| VLAN IDs |
4,000 |
| Total Switched Virtual Interfaces (SVIs) |
1,000 |
| Jumbo frame |
9198 bytes |
| Total routed ports per 3850 stack |
208 |
| Forwarding rate |
130.95 Mpps |
| Wireless |
| Number of access points per switch/stack |
100 |
| Number of wireless clients per switch/stack |
2000 |
| Total number of WLANs per switch |
64 |
| Wireless bandwidth per switch |
Up to 40 Gbps |
| Supported Aironet access point series |
3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Dimensions, weight, acoustic, MTBF, and environmental range |
| Dimensions (H x W x D) |
1.75 x 17.5 x 17.7 Inches (4.45 x 44.5 x 45.0 Centimet) |
| Weight |
17.0 Pounds (7.7 Kilograms) |
| MTBF hours |
303,660 |
| Environmental ranges |
|
With DC power supply
Operating environment and altitude (NEBS)
|
Normal operating temperature and altitudes:
- -5ºC to +45ºC, up to 6000 feet (1800m)
- -5ºC to +40ºC, up to 10,000 feet (3000m)
- -5ºC to +35ºC, up to 13,000 feet (4000m)
Short-term* exceptional conditions:
- -5ºC to +55ºC, up to 6000 feet (1800m)
- -5ºC to +50ºC, up to 10,000 feet (3000m)
- -5ºC to +45ºC, up to 13,000 feet (4000m)
- -5ºC to +45ºC, at sea level with single fan failure
*Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences.
|
|
Relative humidity
|
10% to 95%, noncondensing
|
|
Acoustic noise
Measured per ISO 7779 and declared per ISO 9296
Bystander positions operating to an ambient temperature of 25°C
|
With AC or DC power supply (with 24 PoE+ ports loaded):
- LpA: 43dB typical, 45dB maximum
- LwA: 5.2B typical, 5.5B maximum
Typical: Noise emission for a typical configuration
Maximum: Statistical maximum to account for variation in production
|
|
Storage environment
|
Temperature: -40ºC to 70ºC
Altitude: 15,000 ft
|
|
Vibration
|
Operating: 0.41Grms from 3 to 500Hz with spectral break points of 0.0005 G2/Hz at 10Hz and 200Hz 5dB/octave roll off at each end. |
| Nonoperating: 1.12Grms from 3 to 500Hz with spectral break points of 0.0065 G2/Hz at 10Hz and 100Hz 5dB/octave roll off at each end. |
|
Shock
|
Operating: 30G, 2ms half sine |
| Nonoperating: 55G, 10ms trapezoid |
| Safety and compliance |
| Safety certifications |
UL 60950-1 Second Edition
CAN/CSA-C22.2 No. 60950-1 Second Edition
EN 60950-1 Second Edition
IEC 60950-1 Second Edition
NOM (obtained by partners and distributors)
|
| Electromagnetic emissions certifications |
47CFR Part 15 (CFR 47) Class A (FCC Part 15 Class A)
AS/NZS CISPR22 Class A
CISPR22 Class A
EN55022 Class A
ICES003 Class A
VCCI Class A
EN61000-3-2
EN61000-3-3
KN22 Class A
KCC
CNS13438 Class A
EN55024
CISPR24
KN24
|
| Environmental |
Reduction of Hazardous Substances (ROHS) 5 |
| Noise specifications |
Office Product Spec: 48dBA at 30°C (refer to ISO 7779) |
| Telco |
CLEI code |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
.jpg)
Bạn đang cần tư vấn về sản phẩm: WS-C3850-48T-S ?
Chào anh,
Sản phẩm Cisco WS-C3850-48T-S chưa bao gồm cable Stack đi kèm sản phẩm. Để sử dụng anh có thể tham khảo các mã cable stack dùng cho Cisco Catalyst 3850: STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M.
Thông tin đến anh!
Báo giá 3 chiếc Switch Cisco WS-C3850-48T-S Catalyst 3850 Stackable 48 Port Data IP Base đã được gửi vào mail. Vui lòng check mail để biết được thông tin.
Switch Cisco WS-C3850-48T-S Catalyst 3850 Stackable 48 Port Data IP Base mặc định không có cổng quang mà phải lắp thêm card mới có ạ. Quý khách có thế liên hệ kinh doanh bên em để được tư vấn về giá và nhu cầu mở rộng card ạ, bên em có các dòng sau: C3850-NM-4-1G Catalyst 3850 4 x Gigabit Ethernet Network Module, C3850-NM-2-10G 4 x Gigabit Ethernet/2 x 10 Gigabit Network Module, C3850-NM-4-10G 4 x Gigabit / 4 x 10 Gigabit Ethernet Network Module, C3850-NM-8-10G 8 x Gigabit / 8 x 10 Gigabit Ethernet Network Module, C3850-NM-2-40G Cisco Catalyst 3850 2 x 40 Gigabit Network Module.
CNTTShop đã gửi báo giá qua email, chị vui lòng check inbox nhé.
Thiết bị chuyển mạch WS-C3850-48T-S Catalyst 3850 Stackable 48 Port Data IP Base mặc định là chưa có cồng quang bạn nhé.
